Product image is representative; revision or series may vary. Contact us to request a specific version.
RD63T160
The RD63T160 from Siemens is a trip unit designed for reliable circuit protection. Rated for 1600 A and adaptable to a voltage of 600 VAC, this model supports long time and instantaneous trip functions, making it suitable for industrial applications.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for RD63T160
| Manufacturer | Siemens |
|---|---|
| Product Type | Trip Unit |
| Product Line | SpeedFax |
| Part Number | RD63T160 |
| UPC | 783643239616 |
| Terminal Connections | Line and Load Side Lug |
| Functions | Long Time and Instantaneous Trip |
| Protection Type | Thermal Magnetic |
| Frame Type | RD Frame |
| Interrupt Rating 600 V | 25 KAIC |
| Interrupt Rating at 480 V | 50 KAIC |
| Number of Poles | 3 Poles |
| Rated Voltage | 600 VAC |
| Rated Current | 1600 A |
| Installation Altitude | 1000 MSL |
Siemens presents the RD63T160 trip unit, a critical component in maintaining safety in electrical systems. This unit is rated for a substantial 1600 A and operates effectively at a voltage of 600 VAC. Built with three poles, it offers both long time and instantaneous trip functions, which provide necessary protection against overloads and short circuits.
This trip unit is constructed with a thermal magnetic protection type, facilitating prompt response to electrical faults. It features line and load side lug terminal connections, which simplify installation and ensure reliable operation. The frame type of this unit is categorized as RD, supporting its operational efficiency within designated specifications.
Regarding performance under fault conditions, the RD63T160 has a rated interrupt capacity of 25 KAIC at 600 V and up to 50 KAIC at 480 V. This capability is essential for safeguarding against electrical disruptions. The design also accommodates installation at altitudes of up to 1000 meters above sea level, making it suitable for various environmental conditions.
