Siemens VL Series LGB2B030B

Product image is representative; revision or series may vary. Contact us to request a specific version.

LGB2B030B

|
Need a Specific Revision?

The LGB2B030B from Siemens, part of the VL Series, is a reliable molded case circuit breaker rated for 30 A. It operates with a line voltage of 480 V and is designed with two poles for single-phase applications.

Call for an immediate quote
2 Year DO Supply Warranty
Available
Ships from Raleigh, NC
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for LGB2B030B

ManufacturerSiemens
Product TypeMolded Case Circuit Breaker
Product LineVL Series
Part NumberLGB2B030B
UPC887621220099
Poles2 poles
Interrupt Rating at 240V100 kA
Wire Size14–6 AWG, 12–10 AWG
Phase1 phase
Interrupt Rating at 480V65 kA
Mounting TypePanel
Amperage30 A
Line Side TerminalBusbar
Voltage Rating480 V
Load Side TerminalLug Included
Trip TypeThermal/Magnetic
Request a Repair

Siemens' LGB2B030B encapsulates essential functionality in a molded case circuit breaker format. It is built with two poles, ensuring single-phase operation. Its rated current is 30 A, suitable for various low-voltage applications. Users can expect robust performance with an interrupt rating of 100 kA at 240 V and 65 kA when operating at 480 V.

The breaker accommodates a wire size range from 14 AWG to 6 AWG on one side and 12 AWG to 10 AWG on the other, providing flexibility in installation. It is designed to be mounted on a panel, making setup straightforward in different environments. The line side features a busbar terminal, which aids in easy electrical connections, while the load side includes a lug that facilitates a secure attachment for outgoing circuits.

Additionally, the LGB2B030B uses a thermal/magnetic trip type, ensuring reliable protection against overloading and short circuit incidents. This unit meets essential operational requirements for safety and reliability, making it a valuable component in any electrical installation.
