Product image is representative; revision or series may vary. Contact us to request a specific version.
NGB3B015B
The Siemens NGB3B015B is a molded case circuit breaker designed for industrial applications, featuring a frame type classified as G Frame. Rated for 15 Amperes, it operates efficiently at a voltage of 480Y/277 Volts AC and is assessed for three-phase systems.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for NGB3B015B
| Manufacturer | Siemens |
|---|---|
| Product Type | Molded Case Circuit Breaker |
| Product Line | VL Series |
| Part Number | NGB3B015B |
| GTIN | 00 783643413511 |
| Frame Type | G Frame |
| Voltage Rating | 480Y/277 Volts AC |
| Current Rating | 15 Amperes |
| Poles | 3 Poles |
| Phase | 3 Phase |
| Trip Unit | Thermal Magnetic |
| Trip Function | Long time overload + instantaneous short circuit |
| Mounting | Bolt On |
| Wire Size | 14-10 AWG |
| Interrupting Capacity | 25 kA at 480 Volts, 14 kA at 600 Volts, 100 kA at 240 Volts |
| Certification | UL, CSA, HACR |
| Operating Temperature | -25 to 70 degrees Celsius |
The NGB3B015B molded case circuit breaker from Siemens belongs to the VL Series. This highly functional device is categorized under the G Frame type. Engineered to manage a current rating of 15 Amperes, it operates effectively at a voltage of 480Y/277 Volts AC, aligning with the requirements of industrial three-phase systems.
The circuit breaker incorporates three poles and features a thermal magnetic trip unit. This design ensures that the unit can handle long-time overloads and activate instantaneously in case of short circuits, safeguarding electrical systems from disruptions. The mounting style is bolt-on, simplifying installation processes.
For wiring, the NGB3B015B supports cable sizes in the range of 14 to 10 AWG, providing flexibility in integration. The interrupter capacity is particularly noteworthy, rated at 25 kA for 480 Volts, 14 kA at 600 Volts, and an impressive 100 kA at 240 Volts, making it suitable for high-demand applications. The device is UL, CSA, and HACR certified, ensuring compliance with widely recognized safety standards. Additionally, it is designed to operate in a temperature range from -25 to 70 degrees Celsius, covering various environmental conditions.
