Product image is representative; revision or series may vary. Contact us to request a specific version.
NGG2B050
The Siemens NGG2B050 is a molded case circuit breaker designed for reliable performance. This unit features a rated current of 50 A and operates at a maximum voltage of 600 V, tailored for single-phase applications.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for NGG2B050
| Manufacturer | Siemens |
|---|---|
| Product Type | Molded Case Circuit Breaker |
| Product Line | VL Series |
| Part Number | NGG2B050 |
| UPC | 783643363243 |
| Protection Type | Thermal Magnetic |
| Function | LI - Long Time and Instantaneous |
| Connection Type | Bolt On Connection |
| Frame Type | GG Frame |
| Interrupt Rating at 600Y/347V | 14 KAIC |
| Interrupt Rating at 480 V | 25 KAIC |
| Mounting Type | DIN Rail Mount |
| Number of Poles | 2 Poles |
| Phase Type | 1 Phase |
| Rated Voltage | 600 V |
| Rated Current | 50 A |
Suited for both industrial and commercial settings, the Siemens NGG2B050 molded case circuit breaker delivers dependable circuit protection. Its robust construction supports a rated voltage of 600 V, making it ideal for a variety of applications. This model provides a rated current of 50 A, accommodating the demands of diverse electrical loads.
The NGG2B050 features a thermal magnetic type of protection, which encompasses both long-time and instantaneous trip functions to address overloads and short circuits effectively. Its design incorporates two poles and a connection type that employs bolt-on mechanisms for secure installation.
With an interrupt rating of 14 KAIC at 600Y/347V and 25 KAIC at 480 V, this circuit breaker ensures safety by effectively managing fault conditions. The GG frame type enhances its durability, while its DIN rail mounting capability simplifies integration into various setups. The Siemens NGG2B050 stands as a reliable solution for effective electrical management and protection.
