Yaskawa CIMR CIMR-VA2A0001BAA

Product image is representative; revision or series may vary. Contact us to request a specific version.

CIMR-VA2A0001BAA

|
Need a Specific Revision?

The CIMR-VA2A0001BAA model from Yaskawa is a drive inverter designed to operate with 3-phase AC voltage. With a maximum power capacity of 0.2 kW, it serves a variety of motor control applications efficiently.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for CIMR-VA2A0001BAA

ManufacturerYaskawa
Product LineCIMR
Part NumberCIMR-VA2A0001BAA
Weight3.00 lbs (1.36 kg)
TypeDrive Inverter
Maximum Motor Power0.2 kW
Input Voltage Type3-Phase AC Voltage
Input Voltage Range200-240V AC
Input Frequency50/60 Hz
Input Current1.1/0.7A
Output Voltage Type3-Phase AC Voltage
Output Voltage Range0-240V AC
Output Frequency0-400 Hz
Output Current1.2/0.8A
IP RatingIP20
Approximate Mass0.6 kg
Request a Repair

The Yaskawa CIMR-VA2A0001BAA serves as a drive inverter specifically engineered for controlling motors with precise voltage and current management. This unit is capable of handling a maximum motor power of 0.2 kW, functioning effectively within the 3-phase AC voltage range of 200 to 240 volts. Operating at either 50 Hz or 60 Hz takes full advantage of various industrial power systems.

The inverter’s input current can reach up to 1.1 A and 0.7 A, depending on usage conditions. On the output side, it can produce 3-phase AC voltage ranging from 0 to 240 volts, adjustable to accommodate varying operational needs. The output frequency capability extends to 400 Hz, ensuring flexibility in controlling motor speeds with a peak output current of 1.2 A or 0.8 A under certain conditions.

Weighing approximately 0.6 kg, the CIMR-VA2A0001BAA is compact, yet robust, designed for standard installations. Its IP20 rating signals that this inverter is best suited for indoor use, where it is protected from solid objects larger than 12 mm but not from moisture. This drive inverter is an essential component for achieving efficient motor control in diverse applications.
