Product image is representative; revision or series may vary. Contact us to request a specific version.
DS313
The Yaskawa DS313, part of the GPD series, is an AC drive engineered for three-phase operations. This unit supports an input voltage of 460 V AC and reaches an output frequency of up to 400 Hz, effectively managing both low and high-speed applications.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for DS313
| Manufacturer | Yaskawa |
|---|---|
| Product Line | GPD |
| Part Number | DS313 |
| Weight | 11.00 lbs (4.99 kg) |
| Product | AC Drive |
| Horsepower Rating | 1 HP |
| Input Voltage | 460 V AC |
| Input Phase | Three Phase |
| Input Frequency | 50/60 Hz |
| Output Voltage | 0 to 460 V AC |
| Output Frequency Range | 0.1 to 400 Hz |
| Rated Output Current | 3.2 A |
| Overload Capacity | 150% of rated output current for 1 minute |
| Control Method | Sine-coded pulse width modulation |
| Acceleration/Deceleration Time | 0.1 to 6000 sec |
| Braking | Dynamic Braking Transistor |
| Operating Temperature | -10 to 50 degrees Celsius |
| Enclosure Rating | Open Type (IP00) |
The Yaskawa DS313 is a reliable AC drive that operates efficiently in three-phase applications at 460 V AC input voltage. It has the capability to output voltages ranging from 0 up to 460 V AC. The frequency output can be finely tuned, covering a range from 0.1 to 400 Hz, allowing for extensive control over motor speeds in different scenarios. This drive is rated for 1 horsepower and can supply a continuous output current of 3.2 A, with an overload capability of 150% of its rated output current for up to one minute, which is useful during startup or transient loads.
For optimal performance, the DS313 employs a sine-coded pulse width modulation control method, leading to efficient motor operations. It features a dynamic braking transistor, ensuring swift and reliable braking during operation.
The operational temperature range for this drive is between -10 and +50 degrees Celsius, accommodating various environmental conditions. It is designed with an open-type enclosure (IP00), making it suitable for installation in non-harsh environments. Weighing approximately 5 kg, the DS313 is straightforward to install and manage within existing systems.
- DS3I3
