SGDB-15VD

|

Need a Specific Revision?

The Yaskawa SGDB-15VD is a robust servo drive engineered to provide precise control in motion applications. Operating at an input voltage of 200-230 VAC in a three-phase configuration, it supports a maximum output of 1.3 kW with an output current of up to 10.7 A. The drive uses natural air cooling to maintain optimal performance during operations and incorporates protection features against overcurrent, overvoltage, and overload conditions.

Ships Tomorrow, May 13.

2 Year DO Supply Warranty

In Stock

Ships from Raleigh, NC

Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with DO Supply's 2-year warranty.

Learn more

Warranty

We sell industrial automation parts backed by our 2-year DO Supply Warranty.
Shipping

Same-day domestic and expedited international shipping with UPS, FedEx, DHL, and more.
Payment Methods

AMEX, Visa, MasterCard, Discover, wire transfer, and more, plus flexible payment plans.
Repairs & Exchanges

Repair and exchange services for all existing automation products.
Reseller Options

Drop shipping, blind shipping, and account shipping with no extra fees.

Technical specifications for SGDB-15VD

Manufacturer	Yaskawa
Series	SG Series
Part Number	SGDB-15VD
Product Type	Servo Drive
Input	200-230 VAC, 10 A, 3 Phase
Phase	3 Phase
Output	0-230 VAC, 10.7 A, 1.3 kW, 3 Phase
Frequency	50/60 Hz
Current (Output)	10.7 A
Cooling Method	Natural Air Cooling
Power	1.3 kW
Weight	1.97 kg
Protection	Overcurrent, Overvoltage, and Overload Protection
Current (Input)	10 A
Control Mode	Vector Control

Request a Repair

The Yaskawa SGDB-15VD servo drive is built to handle demanding industrial applications with precision and reliability. Rated for input voltages ranging between 200 and 230 VAC, this unit draws an input current of 10 A across three phases. The servo drive is capable of producing an output voltage that spans from 0 to 230 VAC, effectively delivering up to 10.7 A in output current and achieving a power rating of 1.3 kW.

Operating frequencies for the SGDB-15VD span 50/60 Hz, making it suitable for various operational environments. The drive utilizes a natural air cooling method, ensuring efficient heat dissipation during operation. Constructed with safety in mind, it includes features that protect against overcurrent, overvoltage, and overload situations, thereby enhancing its durability in industrial settings.

Weighing in at 1.97 kg, the servo drive is lightweight yet robust, allowing for easy integration into existing systems. Its vector control mode provides precise and efficient manipulation of motor functions, making it a versatile choice for various applications. This servo drive is designed to meet the rigorous demands of modern automation, delivering consistent performance across a range of operational requirements.
