Yaskawa SG Series SGDM-04AC-SD2A

Product image is representative; revision or series may vary. Contact us to request a specific version.

SGDM-04AC-SD2A

|
Need a Specific Revision?

The SGDM-04AC-SD2A is a servo drive manufactured by Yaskawa, designed specifically for precise motion control applications. It operates within a voltage range of 200 to 230 VAC and delivers an output power of 0.4 kW.

Ships Today.
2 Year DO Supply Warranty
In Stock
Ships from Raleigh, NC
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for SGDM-04AC-SD2A

ManufacturerYaskawa
Product TypeServo Drive
Product LineSG Series
Part NumberSGDM-04AC-SD2A
Minimum Voltage Rating200 VAC
Maximum Voltage Rating230 VAC
Current Rating2.1 A
Output Voltage Rating0 to 230 VAC
Minimum Frequency50 Hz
Maximum Frequency60 Hz
Output Frequency0 to 400 Hz
Rated Output Power0.4 kW
Phase Type3 Phase
Operating Temperature Range0 to 55°C
Storage Temperature Range-20 to 85°C
Request a Repair

The Yaskawa SGDM-04AC-SD2A servo drive offers robust performance for demanding applications. Its voltage range spans from a minimum of 200 VAC to a maximum of 230 VAC, ensuring compatibility with various systems. This device features a current rating of 2.1 A and provides adjustable output voltage from 0 to 230 VAC depending on operational needs.

Frequency capabilities enhance its versatility, with a minimum frequency of 50 Hz and a peak frequency of 60 Hz. The output frequency can reach up to 400 Hz, adapting easily to various performance requirements. This servo drive's rated output power stands at 0.4 kW, making it suitable for a range of tasks where precise control is paramount.

The design incorporates a 3-phase configuration, further supporting efficient operation in industrial environments. Temperature resilience is built-in, with an operating range of 0 to 55°C, allowing it to function effectively in typical conditions. For storage purposes, it can safely remain in temperatures ranging from -20 to 85°C. All these features combined demonstrate a well-rounded servo drive that can meet diverse automation challenges.
