Yaskawa SGM Sigma-7 Series SGM-08V312

Product image is representative; revision or series may vary. Contact us to request a specific version.

SGM-08V312

|
Need a Specific Revision?

The Yaskawa SGM-08V312 is an advanced AC servo motor designed for precise control applications. It offers a power rating of 750 W at a voltage of 200 V and supports a maximum speed of 3000 RPM.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for SGM-08V312

ManufacturerYaskawa
Product LineSGM Sigma-7 Series
Part NumberSGM-08V312
Weight7.56 lbs (3.43 kg)
ProductAC Servo Motor
Power Rating750 W
Voltage Rating200 V
Current Rating44 A
Torque Rating2.39 Nm
Speed3000 RPM
Insulation ClassB
Maximum Ambient Temperature60 degrees Celsius
Minimum Ambient Temperature0 degrees Celsius
Operating Humidity Limit80% (non-condensing)
Storage Humidity Limit80% (non-condensing)
Operating Altitude1000 meters above sea level
Request a Repair

The Yaskawa SGM-08V312 model serves as an efficient AC servo motor, optimized for precise applications. Rated at 750 W in power and 200 V in voltage, it performs with a maximum current of 44 A. This motor achieves a peak speed of 3000 RPM, making it suitable for tasks requiring quick response times and dependable torque delivery of 2.39 Nm.

Designed for varied industrial environments, this motor operates within a temperature range between 0 and 60 degrees Celsius. The insulation is classified as Class B, offering reliable performance amid prevalent industrial heat levels. In terms of humidity, it supports both operating and storage conditions with a limit of 80%, ensuring durability in potentially moist surroundings.

The capability to function at altitudes of up to 1000 meters ensures this model can be utilized in diverse geographical locations. The entire unit weighs 7.56 lbs, which facilitates ease of installation and integration into larger systems. The SGM-08V312 is structured for durability and precision, catering to the complex demands of modern automation tasks.
