Yaskawa Sigma 5 SGDV-3R5D11A

Product image is representative; revision or series may vary. Contact us to request a specific version.

SGDV-3R5D11A

|
Need a Specific Revision?

The Yaskawa SGDV-3R5D11A is an AC servo drive designed to offer reliable performance in demanding applications. It operates within a voltage range of 380 to 480 volts, making it versatile for varying operational needs.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for SGDV-3R5D11A

ManufacturerYaskawa
Product LineSigma 5
Part NumberSGDV-3R5D11A
Weight3.25 lbs (1.47 kg)
ProductAC Servo Drive
Input Voltage380 to 480 V
Frequency50/60 Hz
Input Current2.5 A
Number of Phases3
Output Voltage0 to 480 V
Output Frequency0 to 300 Hz
Output Current3.5 A
Power Rating1 kW
Protection ClassIP20
Surrounding Air Temperature0 to 55 degrees Celsius
Request a Repair

The Yaskawa SGDV-3R5D11A AC servo drive is engineered for effective motor control in various applications. It supports an input voltage ranging from 380 to 480 volts, accommodating both 50 Hz and 60 Hz frequency specifications. The drive draws a current of 2.5 amps and operates with a three-phase power system. On the output side, it can deliver voltages anywhere from 0 to 480 volts, along with an output frequency capability that extends from 0 to 300 Hz. With a maximum output current of 3.5 amps and a power rating of 1 kW, the SGDV-3R5D11A is equipped to handle considerable loads.

Protection is classified at IP20, which means it effectively minimizes the ingress of solid particles but is not suitable for moisture-laden environments. The device operates efficiently within a temperature range of 0 to 55 degrees Celsius, ensuring reliable performance under varying climatic conditions. The overall dimensions of the servo drive are compact, measuring 110 mm in width, 160 mm in height, and 180 mm in depth, which weighs in at 2.7 kg. This servo drive balances performance with practicality, making it a solid choice for enhancement in automated systems.
