Product image is representative; revision or series may vary. Contact us to request a specific version.
SGDV-5R4D01A
The Yaskawa SGDV-5R4D01A AC servo drive operates on an input voltage rating of 400 Volts AC and supports a main supply voltage ranging from 380 to 480 Volts AC. Designed for efficiency, it maintains a continuous output current rating of 5.4 Amperes and can handle instantaneous peaks up to 14 Amperes. With a power output of 1.5 kilowatts, its frequency response reaches 1,000 Hertz, making it suitable for high-performance applications.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for SGDV-5R4D01A
| Manufacturer | Yaskawa |
|---|---|
| Product Type | AC Servo Drive |
| Product Line | Sigma 5 |
| Part Number | SGDV-5R4D01A |
| Weight | 2.75 lbs (1.25 kg) |
| Main Circuit Supply Voltage | 380 to 480 Volts AC |
| Input Voltage Rating | 400 Volts AC |
| Input Phase Type | 3-phase input |
| Input Frequency | 50 to 60 Hertz |
| Continuous Output Current Rating | 5.4 Amperes |
| Instantaneous Output Current | 14 Amperes (maximum) |
| Rated Power | 1.5 kilowatt |
| Frequency Response | 1,000 Hertz |
| Control Power Supply Rating | 24 Volts DC |
| Ambient Operating Temperature | 0 to 40°C (in a non-condensing environment) |
| Storage Temperature | -20 to 85°C (in a non-condensing environment) |
| Protection Rating | IP10 |
| Operating/Installation Altitude | 3,280 feet (1,000 meters) above sea level |
| Resistor Type | Built-in or external regenerative resistor |
The SGDV-5R4D01A, a Yaskawa's Sigma 5 series model, is an AC servo drive that delivers robust performance in demanding applications. This device is rated for an input voltage of 400 Volts AC and can accommodate a main circuit supply voltage ranging from 380 to 480 Volts AC. It primarily operates on a 3-phase input with a frequency capability of 50 to 60 Hertz, allowing for versatile integration into existing systems.
Regarding current handling, the drive provides a continuous output current of 5.4 Amperes and can deliver a maximum instantaneous output current of 14 Amperes. With a rated power of 1.5 kilowatts, this servo drive ensures efficient operation, especially when responding to dynamic loads. The frequency response of up to 1,000 Hertz further enhances its suitability for precise control applications.
The SGDV-5R4D01A's ambient operating temperature is between 0 and 40°C, maintained in non-condensing environments. For storage, it can handle a temperature range of -20 to 85°C under similar conditions, demonstrating its durability. Featuring an IP10 protection rating, it is designed for operation in environments where environmental concerns are minimal. The installation location can reach 3,280 feet (1,000 meters) above sea level, ensuring adaptability in varied installations.
The control power supply is rated at 24 Volts DC, providing reliable support for the drive's function. Both built-in or external regenerative resistors can be utilized for braking purposes, offering flexibility in application setups.
