Yaskawa Sigma 5 SGDV-5R5A01A

Product image is representative; revision or series may vary. Contact us to request a specific version.

SGDV-5R5A01A

|
Need a Specific Revision?

The Yaskawa SGDV-5R5A01A belongs to the Sigma 5 series and is an AC servo drive suitable for 3-phase input systems. It operates with a rated power of 750 Watts and is designed for a voltage rating of 200 Volts AC.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for SGDV-5R5A01A

ManufacturerYaskawa
Product TypeAC Servo Drive
Product LineSigma 5
Part NumberSGDV-5R5A01A
Weight5.00 lbs (2.27 kg)
Input Phase Type3-phase input
Rated Power750 Watts
Input Voltage Rating200 Volts AC
Ambient Operating Temperature0 to 40°C (in a non-condensing environment)
Continuous Output Current Rating5.5 Amperes
Instantaneous Output Current16.9 Amperes (maximum)
Main Circuit Supply Voltage200 to 230 Volts AC
Overvoltage CategoryCategory III
Input Frequency50 to 60 Hertz
Storage Temperature-20 to 85°C (in a non-condensing environment)
Operating/Installation Altitude3,280 feet (1,000 meters) above sea level
Resistor TypeBuilt-in or external regenerative resistor
Control Interface TypeAnalog voltage and pulse train command
Protection RatingIP10
Request a Repair

The SGDV-5R5A01A from Yaskawa is a precise AC servo drive for applications requiring three-phase input. With a rated power of 750 Watts and an input voltage rating of 200 Volts AC, it is engineered for consistent operation in various environments. The continuous output current is rated at 5.5 Amperes, while it can handle an instantaneous output current peaking at 16.9 Amperes. This drive is built to perform efficiently within an ambient temperature range from 0 to 40°C and is designed for non-condensing conditions.

For storage, it can withstand temperatures from -20 to 85°C. The input frequency compatibility spans from 50 to 60 Hertz, making it versatile for multiple installations. The main circuit supply voltage accommodates a range of 200 to 230 Volts AC. Regarding protective measures, it falls under overvoltage category III and features an IP10 protection rating. Application installations can occur at altitudes up to 3,280 feet (1,000 meters) above sea level, enhancing its usability in various settings. The drive supports analog voltage and pulse train command control interfaces and can utilize a built-in or external regenerative resistor for optimal performance.
