Yaskawa Sigma Series SGDA-08ASY151

Product image is representative; revision or series may vary. Contact us to request a specific version.

SGDA-08ASY151

|
Need a Specific Revision?

The Yaskawa SGDA-08ASY151 is a robust servo drive designed for efficient single-phase operation. Capable of delivering 1 HP output power, it supports both speed and torque control for versatile applications.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for SGDA-08ASY151

ManufacturerYaskawa
Product TypeServo Drive
Product LineSigma Series
Part NumberSGDA-08ASY151
Weight2.94 lbs (1.33 kg)
SeriesAC Drives
Single-Phase VoltageSupported
Power Supply Voltage200V
Output Power1 HP
Speed ControlSupported
Torque ControlSupported
Current11 Amps
Operating Temperature0 to 40 degrees Celsius
Storage Temperature0 to 50 degrees Celsius
Operating Humidity80% max. RH (non-condensing)
Storage Humidity80% max. RH (non-condensing)
Operating Altitude1000m max. above sea level
Storage Altitude1000m max. above sea level
Operating EnvironmentClean indoor environment with no corrosive chemicals
Request a Repair

In the Yaskawa SGDA-08ASY151 servo drive, practicality meets functionality. This unit is tailored for single-phase voltage operation with a power supply rating of 200 volts. Users can expect reliable performance with an output capability of 1 HP. It also features both speed and torque control mechanisms, enhancing its suitability for a range of applications that demand precise motor management.

This servo drive operates at a current of 11 Amps. It performs effectively within a specified temperature range of 0 to 40 degrees Celsius, making it fit for typical indoor settings. For storage, it is rated to withstand temperatures from 0 to 50 degrees Celsius.

Humidity levels are managed with a maximum of 80% relative humidity for both operation and storage, without the threat of condensation impairing its function. This model is also designed for altitude use, functioning reliably up to 1000 meters above sea level in either operating or storage conditions. Users must ensure the drive is placed in clean indoor environments that are free from corrosive chemicals for optimal performance and longevity.
