Yaskawa Sigma Series SGDV-5R4D11A

Product image is representative; revision or series may vary. Contact us to request a specific version.

SGDV-5R4D11A

|
Need a Specific Revision?

The Yaskawa SGDV-5R4D11A belongs to the Sigma Series and functions as a servopack. Designed for versatility, this model operates within a voltage range of 380 to 480 VAC, accommodating both 50 and 60 Hz input frequencies while delivering an output power of 1.5 kW.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for SGDV-5R4D11A

ManufacturerYaskawa
Product TypeServopack
Product LineSigma Series
Part NumberSGDV-5R4D11A
Weight7.19 lbs (3.26 kg)
Input Frequency50/60 Hz
Input Voltage380-480 VAC
Input Current3.7 A
Output Current5.4 A
Protection RatingIP10
Output Voltage0-480 VAC
Output Power1.5 kW
Phase3-Phase
Output Frequency0-300 Hz
Surrounding Air Temperature0-55°C
Cooling MethodForced air cooling
EfficiencyHigh
Request a Repair

The Yaskawa SGDV-5R4D11A servopack is engineered for precision control in industrial automation. It operates effectively at input voltages ranging from 380 to 480 VAC with the flexibility to accommodate input frequencies of 50 and 60 Hz. This model is capable of handling a 3-phase input current of 3.7 A and directly delivers an output current of up to 5.4 A to connected devices.

In terms of power output, the servopack provides 1.5 kW, ensuring sufficient energy for various applications. Additionally, its output voltage ranges from 0 to 480 VAC, and it supports output frequencies between 0 and 300 Hz, making it suitable for a wide array of tasks. Built to operate in environments with temperatures ranging from 0 to 55°C, it effectively utilizes forced air cooling to maintain optimal performance.

The SGDV-5R4D11A also features an IP10 protection rating, ensuring minimal resistance to dust and moisture. Weighing 3.25 kg, it's designed to integrate smoothly into existing setups while contributing to the overall efficiency needed for modern industrial applications. This device embodies high efficiency, allowing it to perform reliably under various conditions.
