Yaskawa VS Mini CIMR-J7AA20P1

Product image is representative; revision or series may vary. Contact us to request a specific version.

CIMR-J7AA20P1

|
Need a Specific Revision?

The CIMR-J7AA20P1 model from Yaskawa belongs to the VS Mini series and functions as an AC inverter drive. It offers a compact and efficient solution for various applications, handling input voltages from 200 to 230 volts AC with a three-phase configuration.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for CIMR-J7AA20P1

ManufacturerYaskawa
Product LineVS Mini
Part NumberCIMR-J7AA20P1
Weight1.00 lbs (0.45 kg)
TypeAC Inverter Drive
Input Voltage200–230 V AC
Input Phase3-Phase
Input Frequency50/60 Hz
Input Current1.1 A
Output Voltage0–230 V AC
Output Frequency0.1–400 Hz
Output Current0.8 A
Power Rating0.13 HP
Request a Repair

The Yaskawa CIMR-J7AA20P1 is designated as an AC inverter drive and fits into the compact VS Mini series. Operating efficiently within an input voltage range of 200 to 230 volts AC, this three-phase inverter accommodates both 50 Hz and 60 Hz input frequencies. The drive has a maximum input current of 1.1 Amps, catering to a wide range of applications.

Designed for adaptability, the output voltage is configurable from 0 volts to a maximum of 230 volts AC. It also supports an impressive range for output frequency, running from 0.1 Hz up to 400 Hz. The inverter can manage an output current of 0.8 Amps, ensuring it meets the demands of numerous electric motors. With a small power rating of 0.1 kW or 0.13 HP, it is well-suited for applications requiring lower power and compact solutions.

Weighing in at just 0.41 kg (0.90 lbs.), this inverter is lightweight, facilitating easy installation and integration into existing systems. Overall, the CIMR-J7AA20P1 combines efficiency and functionality, making it a reliable choice for variable frequency motor control.
