1305-BA01A-HAP

Revisions: Ser A
Description: 1305-BA01A-HAP 1305 AC Drives with IP 30 (NEMA Type 1) enclosure, 380-460V, Three Phase rating and Programmer Only interface. English language
Available Now
Request a quote for 1305-BA01A-HAP

Description: 1305-BA01A-HAP 1305 AC Drives with IP 30 (NEMA Type 1) enclosure, 380-460V, Three Phase rating and Programmer Only interface. English language

top legal disclaimer
disclaimer
credit cards
better business bureau
Revisions: Ser A

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via DHL, UPS, Fedex, and TNT
Repairs: We offer repair service for the 1305-BA01A-HAP.
Exchange: Exchange credit for your defective unit available.

To speak to a sales representative for pricing & lead time:

phone

International
919-205-4392
phone

International
919-205-4392

Rated 4.8 with 17 reviews

    Technical Specifications for 1305-BA01A-HAP

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1305-BA01A-HAP
Product Line1305 AC Drives
Enclosure TypeIP 30 (NEMA Type 1)
Voltage380-460V, Three Phase
Human Interface ModulesProgrammer Only
LanguageEnglish
Horsepower0.5 HP
Motor Rating (kW, Output Current).37 kW 1.3 A
Product Lifecycle Status*Discontinued/Obsolete

*The Allen Bradley 1305-BA01A-HAP has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 1305-BA01A-HAP units instead of migration.

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1305-BA01A-HAP
Product Line1305 AC Drives
Enclosure TypeIP 30 (NEMA Type 1)
Voltage380-460V, Three Phase
Human Interface ModulesProgrammer Only
LanguageEnglish
Horsepower0.5 HP
Motor Rating (kW, Output Current).37 kW 1.3 A
Product Lifecycle Status*Discontinued/Obsolete

*The Allen Bradley 1305-BA01A-HAP has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 1305-BA01A-HAP units instead of migration.

s

About 1305-BA01A-HAP

The Allen-Bradley 1305-BA01A-HAP is a product in the Bulletin 1305 AC Drive series. The catalog number indicates the unique features of the drives. “1305” indicates the bulletin number. “B” indicates the input voltage, which is 380-460V AC. “A01” identifies the nominal current rating. “A” indicates that this device uses the NEMA Type 1 (IP30) enclosure. The fifth position is for the language code, this type of device does not have a language code, therefore, it uses the default language which is the English language. “HAP” identifies the type of Human Interface Module (HIM) the device uses. The HIM features a backlit LCD display and computer-like programming keys. It can also be removed from the 1305-BA01A-HAP drive.
The 1305-BA01A-HAP can withstand 1G of vibrations. It does not offer special cooling equipment but uses natural convection as its cooling method. The atmospheric temperature ranges between 0 and 50° C with the enclosure and between 0 and 40° C without one. The storage temperature ranges from -40-70° C, at 0-95% relative humidity (non-condensing). Use the 1305 Dynamic Brake Kits for additional AC Dynamic Braking Torque with an output of 150% with an external resistor and of 100% without an external resistor. The 1305-BA01A-HAP measures 170mm x 195mm x 179mm in overall dimensions and it weighs approximately 3.6 kg (8lb).
The 3-phase AC induction motor for this design uses 0.37kW (0.5HP) and it has an output current of 1.3A. It has an adjustable output voltage between 0V and the desired input voltage, a programmable output frequency from 0-400Hz, and a maximum of 250mA ScanPort load i.e. if all adapters are combined. The voltage is operational in a range between 340 and 500V, 47 and 63Hz with an input kVA of 0.9. The 1305-BA01A-HAP has 97.5% efficiency rating and a displacement of 0.8 (lagging) and with 21W power dissipation.

Repair Services for 1305-BA01A-HAP

Type Lead Time Price Action
Repair Service 2-4 weeks $682.77cartAdd to Cart

Our highly skilled technicians can repair your 1305-BA01A-HAP. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions for 1305-BA01A-HAP

Please refer to the manual for more information about the 1305-BA01A-HAP such as the wiring diagrams, data sheets, firmware information and migration or obsolescence details.

Revision Part # Also Known as Availability
1305-BA01A-HAP Ser A
1305-BA01A-HAP/A, Series A, Rev A Request Quote
Common misspellings:
  • l305-BA01A-HAP
  • 13o5-BA01A-HAP
  • 1305-8A01A-HAP
  • 1305-BAo1A-HAP
  • 1305-BA0lA-HAP
  • 1305BA01AHAP

Dimensions For 1305-BA01A-HAP

Size
Input Type
Panel Cutout Height in mm
Panel Cutout Width in mm
Terminal Height in mm
Terminal Width in mm
Terminal Overall Depth in mm
Terminal Mounted Depth in mm

Dimensions For 1305-BA01A-HAP

Width 6-11/16 in. (170 mm)
Height 7-11/16 in. (195 mm)
Depth w/o Pot. 7-1/4 in. (179 mm)
Depth w/ Pot. 7-1/4 in. (184.1 mm)
Weight 8.0 lb (3.6 kg)
