1305-BA04A-HA1

Revisions: Ser A Ser B Ser C
Description: 1305-BA04A-HA1 1305 AC Drives with IP 30 (NEMA Type 1) enclosure, 380-460V, Three Phase rating and HIM with Analog Speed Pot interface. English language
In Stock Ships Today
Request a quote for 1305-BA04A-HA1

Description: 1305-BA04A-HA1 1305 AC Drives with IP 30 (NEMA Type 1) enclosure, 380-460V, Three Phase rating and HIM with Analog Speed Pot interface. English language
About | Products Specs

DO Supply is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with DO Supply's 1-year warranty

Rockwell Disclaimer: The product is used surplus. DO Supply is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because DO Supply is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. DO Supply also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. DO Supply also makes no representations as to your right to install any such firmware on the product. DO Supply will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

disclaimer
credit cards
better business bureau
Revisions: Ser A Ser B Ser C

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via UPS, DHL, and TNT
Repairs: We offer repair service for the 1305-BA04A-HA1.
Exchange: Exchange credit for your defective unit available.
Conditions: We sell preowned surplus and refurbished parts.

To speak to a sales representative for pricing & lead time:


Rated 4.4 with 21 reviews

    Technical Specifications for 1305-BA04A-HA1

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1305-BA04A-HA1
Product Line1305 AC Drives
Enclosure TypeIP 30 (NEMA Type 1)
Voltage380-460V, Three Phase
Human Interface ModulesHIM with Analog Speed Pot
LanguageEnglish
Horsepower2 HP
Motor Rating (kW, Output Current)1.5 kW 4 A
Product Lifecycle Status*Discontinued/Obsolete

*The Allen Bradley 1305-BA04A-HA1 has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 1305-BA04A-HA1 units instead of migration.

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1305-BA04A-HA1
Product Line1305 AC Drives
Enclosure TypeIP 30 (NEMA Type 1)
Voltage380-460V, Three Phase
Human Interface ModulesHIM with Analog Speed Pot
LanguageEnglish
Horsepower2 HP
Motor Rating (kW, Output Current)1.5 kW 4 A
Product Lifecycle Status*Discontinued/Obsolete

*The Allen Bradley 1305-BA04A-HA1 has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 1305-BA04A-HA1 units instead of migration.

s

About 1305-BA04A-HA1

The Allen-Bradley 1305-BA04A-HA1 is a variable speed drive in the Bulletin AC drive series. It has a 3-phase motor rating of 1.5kW or 2HP and an output current of 4mA. The output voltage can be adjusted from 0V to any desired input voltage. The output frequency is programmable to values between 0 and 400Hz. The overall ScanPort load is 250mA at highest. It has a speed controller for the 3-phase AC induction motor with an input voltage rating of 380-460V and a frequency rating of 50-60Hz. The 1305-BA04A-HA1 is operational between 340 and 500V and 47 and 63Hz. The input kVA has a value of 3.1. The power factor or displacement is 0.8 (lagging) with an efficiency rating of 97.5%. The power dissipation for this type is 52W.

As indicated in the catalog number, the enclosure used for the 1305-BA04A-HA1 is an IP30 (NEMA 1) standard type. The control input type for this device is a contact closure with an internal 5V supply. Grounding or applying external voltage causes damage to the device. The Start, Stop, and Forward/Reverse Control Input is configurable for 2 or 3-wire control. Use SW1, SW2, and SW3 for configuring the control of the 7 preset speeds and the 2 acceleration/deceleration times. To enable drive operation, use the interlock input. The external speed potentiometer has a value of 10KΩ or 1 watt. The analog input for 4-20mA has an input impedance of 250Ω non-isolated for 0-10V and it has an input impedance of 100KΩ non-isolated.

The control output for Programmable Output 1 is a relay contact form and it has a resistive rating of 155V AC/30V DC and an inductive rating of 115V AC/30V DC, 2A. Programmable Output 2 for the open collector (sink) has values of 24V DC, 20%, 50mA maximum. The Analog Output ranges from 0-10V DC and its 4,000 Ohms, and the 8-bit resolution is less than or equal to the load impedance. The PWM algorithm is a sine-weighted PWM output. The V/Hz has a programmable function. The AC Dynamic Braking Torque is it valued at 150% with an external resistor and only 50% without one. As indicated in the catalog number, the Human Interface Module (HIM) used for the 1305-BA04A-HA1 is an analog speed potentiometer type of HIM.



This content was written and compiled by DO Supply and should not be copied.

Repair Services for 1305-BA04A-HA1

Type Lead Time Price Action
Repair Service 2-4 weeks $562cartAdd to Cart

Our highly skilled technicians can repair your 1305-BA04A-HA1. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.
