The Allen-Bradley 1336 PLUS drives are a family of microprocessor-based AC drives with sensorless vector control that are designed to provide control for 3-phase motors in critical applications where accurate torque and speed control is necessary. The 1336 PLUS drive series offers easy-to-use and cost-effective motor control solutions to applications with even the tightest speed requirements, and they come with built-in protection features that help to improve performance and save maintenance costs caused by unscheduled downtimes. The 1336 PLUS drives have A1, A2, A3, A4, B1/B2, C, D, E, G, and G frames with input ratings from 200 to 600 Volts AC and 0.37 to 448 kilowatts (0.5 to 600 Horsepower). All 1336 PLUS drives have both variable and constant torque capability, and each drive is sized to 115% of the full load Amps for variable torque applications, and 150% of the full load Amps for constant torque applications.
The 1336 PLUS drives employ the Pulse Width Modulation (PWM) control with programmable carrier frequencies from 2 to 10 KiloHertz. Depending on the application type, the operators can choose between the standard Volts per Hertz control method, which offers customizable Volts per Hertz curve and it is suitable for centrifugal and HVAC applications, and the sensorless vector control (SVC), which provides tighter speed control even under varying loads, higher starting torque, and lower speed operation than other control methods. The 1336 PLUS drives offer easy-to-use human-machine interface module options, communication options (single-point remote I/O, RS-232/422, DF1, DH-485, and DeviceNet networks), and the control interface card option with or without an encoder interface. This drive series features easy-to-read display interface options that support multiple languages for easy configuration, diagnostics, and troubleshooting processes. The 1336 PLUS drive series features drives with IP 00 (Open), IP 20, IP 54, and IP 65 enclosures, and they have a non-derating operating temperature range of 0 to 40 degrees Celsius.
Browse available units in our catalog of 1336 PLUS Drives.
This drive operates on input frequencies of 48 to 62 Hz and can output frequencies ranging from 0 to 400 Hz. With a voltage tolerance of ±10 percent, this module is capable of providing output voltage
This AC drive features an IP00 rating, indicating an open-type enclosure, providing access to internal components. It supports English as the designated language group. This device operates optimally
This drive boasts a rated output current of 19 A and supports an output frequency range from 0 to 400 Hz. Its control method employs sine-coded PWM technology, ensuring smooth motor operation. The uni
This drive features an output voltage range of 0 to 240 V AC and provides an output current capacity of 17 A. It is capable of accepting a 3-phase input frequency of 47 to 63 Hz. The unit includes one
Engineered for reliability, this AC drive operates efficiently with a minimum operating temperature of 0°C and a maximum of 40°C. The unit can be stored in temperatures from -40°C to 70°C. With an IP2
This AC drive operates within a rated current of 30 A and possesses an open-type enclosure rated as IP00. It can function effectively in temperatures ranging from 0°C to 50°C, while its storage capabi
This variable frequency drive operates within a wide output frequency range from 0 to 400 Hz, making it suitable for versatile control applications. It is rated for a maximum output current of 18 A an
This AC drive features an open enclosure rated at IP00, suitable for non-harsh environments. It provides a vertical mounting orientation and operates within a temperature range of 0 to 50 °C. This mod
This AC drive operates efficiently with a protection class of IP20. The unit functions optimally at an efficiency rate of 97.50%. It has both overvoltage and undervoltage trip settings of 570 VAC and
This model supports a minimum operating frequency of 50 Hz and maximum of 60 Hz. With a rated current capacity of 13 A, the drive is classified under IP00 protection and is designed with an open-type
