The 1336 PLUS II drive series by Allen-Bradley is a series of compact and high-performance adjustable frequency AC drives with sensorless vector control that is designed to provide speed control solutions to a wide range of applications. The 1336 PLUS II drives offer common designs, control interface options, and device communication options that are found across the entire series which makes integration, installation, operator training, and maintenance simple. The 1336 PLUS II drives are available in ratings from 0.37 to 448 kiloWatts (0.5 to 600 Horsepower) with voltage ranges from 200 to 240 Volts AC, 380 to 480 Volts AC, and 500 to 600 Volts AC. They are available in 9 different frames (A1, A2, A3, A4, B1, B2, C, D, and E), and they have constant torque and variable torque capabilities. The 1336 PLUS II drives use programmable pulse width modulation frequency with adjustable output voltage for exceptional speed and torque control, and these outputs can be easily fine-tuned to provide the desired performance under varying loads.
The 1336 PLUS II drives have built-in fault detection and overload protection, and they also have real-time preventive and fault reporting capabilities that alert operators to any faults through alarms and plain text diagnostic messages for quick corrective measures. The 1336 PLUS II drives offer the users motor control with the standard Volts per Hertz control (with a customizable Volts per Hertz curve) and the sensorless vector control (SVC) which provide outstanding speed and torque performance, and a higher starting torque of up to 250%. The 1336 PLUS II drives have configurable I/O interfaces, optional human-machine interface modules, Remote I/O, RS-232/422, DeviceNet, and Enhanced DeviceNet modules, control interface modules (with and without encoder interfaces), and multiple language options. The 1336 PLUS II drives are available in IP 00 (Open), IP 20 (NEMA Type 1), or IP 54 (NEMA Type 12) installations, and they are CE, CSA, UL, C-TICK certified.
Browse available units in our catalog of 1336 PLUS II Drives.
The 1336F-B020-AA-EN-GM5-HAS2 adjustable frequency drive is an industrial drive manufactured by Allen-Bradley/Rockwell Automation for an input voltage range of 380 to 480 Volts AC. The drive has an ou
The 1336F-B020-AA-EN-HCS1-LA4-L4 drive is manufactured by Allen-Bradley/Rockwell Automation and it is part of the 1336 PLUS II series. The drive has an output power rating of 15 kilowatts (20 Horsepow
This adjustable frequency drive offers a power rating of 20 Hp and supports input voltages from 380V to 480V AC. The device has an IP00 rating and an open type enclosure, making it fit for specific us
This drive is designed for variable torque applications, with an input kVA rating of 18.6 kVA and a corresponding input current rating of 22.4 A. For constant torque usage, the input kVA ranges from 1
This adjustable frequency drive provides a broad output frequency range of 0 to 400 Hz. The drive operates efficiently, boasting an efficiency rating of 97.50%. It features a NEMA 1 enclosure and is c
This drive operates at an input kVA of 20.4 for variable torque and can manage current levels of 24.5A. The output power matches the input configuration, reaching 19.1 kVA in both variable and constan
Designed for indoor environments, this drive features an IP20 rating and a NEMA 1 enclosure type. Its operational temperature ranges from 0°C to 40°C, while storage capabilities extend from -40°C to 7
This adjustable frequency AC drive operates within a power rating of 30 kW. The enclosure is of open type, providing basic environmental protection. It supports a temperature range for operation from
The 1336F-A007-AA-EN-HCSP drive is an adjustable frequency AC drive from the 1336 Plus II series by Allen-Bradley/Rockwell Automation. The drive has real-time diagnostics, status LED indicators, a rem
The Allen-Bradley 1336F-A007-AA-EN935-HCS2-LA2-LA3-L6 1336 Plus II adjustable frequency AC drive is designed to provide exceptional motor control in high-performance motion control applications. This
