The 1336 PLUS II drive series by Allen-Bradley is a series of compact and high-performance adjustable frequency AC drives with sensorless vector control that is designed to provide speed control solutions to a wide range of applications. The 1336 PLUS II drives offer common designs, control interface options, and device communication options that are found across the entire series which makes integration, installation, operator training, and maintenance simple. The 1336 PLUS II drives are available in ratings from 0.37 to 448 kiloWatts (0.5 to 600 Horsepower) with voltage ranges from 200 to 240 Volts AC, 380 to 480 Volts AC, and 500 to 600 Volts AC. They are available in 9 different frames (A1, A2, A3, A4, B1, B2, C, D, and E), and they have constant torque and variable torque capabilities. The 1336 PLUS II drives use programmable pulse width modulation frequency with adjustable output voltage for exceptional speed and torque control, and these outputs can be easily fine-tuned to provide the desired performance under varying loads.
The 1336 PLUS II drives have built-in fault detection and overload protection, and they also have real-time preventive and fault reporting capabilities that alert operators to any faults through alarms and plain text diagnostic messages for quick corrective measures. The 1336 PLUS II drives offer the users motor control with the standard Volts per Hertz control (with a customizable Volts per Hertz curve) and the sensorless vector control (SVC) which provide outstanding speed and torque performance, and a higher starting torque of up to 250%. The 1336 PLUS II drives have configurable I/O interfaces, optional human-machine interface modules, Remote I/O, RS-232/422, DeviceNet, and Enhanced DeviceNet modules, control interface modules (with and without encoder interfaces), and multiple language options. The 1336 PLUS II drives are available in IP 00 (Open), IP 20 (NEMA Type 1), or IP 54 (NEMA Type 12) installations, and they are CE, CSA, UL, C-TICK certified.
Browse available units in our catalog of 1336 PLUS II Drives.
This drive features an IP20 protection level and is housed in a NEMA 1 enclosure, ensuring operational reliability. The unit is designed for ambient operation between 0°C and 40°C and can be stored sa
For effective use, this drive boasts a NEMA 1 enclosure with an IP20 rating. It supports operation in an ambient temperature range of 0 to 40°C and a storage environment from -40 to 70°C. Installation
Offering an IP20 rating, the 1336F-BRF50 features NEMA 1 enclosure standards. It supports a power output of 3.7 kW and includes a human-machine interface module that acts as both a programmer and cont
This drive has a power capacity of 3.7 kW and comes in an open-type enclosure with an IP00 protection rating. It is built for optimal performance in environments with temperatures ranging from 0 to 50
Designed for AC applications, this adjustable frequency drive operates with a constant torque input of 13.6 A across a kVA range of 8.9-11.3. With a variable torque output rating of 15.4 A, it manages
The drive supports 5.5 kW of power and facilitates both AC and DC input voltage ranges. Equipped for NEMA 1 applications, it boasts an IP20 rating, providing adequate protection for indoor environment
Operating within a voltage range of 500 to 600 volts AC, the 1336F-C040-AA-EN provides output current capabilities of 45 amps with a maximum input current of 44 amps. The drive features configurable o
This Allen Bradley AC drive operates effectively at rated input voltages of 500-600V AC and has a DC voltage rating of 775V. It provides a horsepower output of 10 HP and complies with IP20 rating in a
This drive is engineered with a three-phase input type and has a frequency tolerance between 48 and 62 Hertz. It operates within an output frequency range of 0 to 400 Hertz and features sine-coded Pul
This adjustable frequency drive operates efficiently at an AC voltage rating of 380-480 VAC and can handle DC voltages between 513 to 620 V. The model has a horsepower rating of 2 and is enclosed in a
