1336-QPRE-SP1C

Revisions: Ser A
Description: The Allen-Bradley 1336-QPRE-SP1C is the pre-charge transistor for the 1336 PLUS/PLUS II/FORCE/IMPACT drives. Specifically, the 1336-QPRE-SP1C is compatible with the following: 7.5 - 15 HP /230V Series C and up PLUS/FORCE/IMPACT drives, 7.5 - 15 HP /230V Series A and up PLUS II drives, 7.5 - 30 HP/460V Series C and up PLUS/FORCE/IMPACT drives and 15-30 HP /460V PLUS II drives. The 1336-QPRE-SP1C pre-charge transistor is available as a spare part for the above-mentioned drives. The presence of dangerously high voltage levels requires that drive repair and maintenance should be executed only by experienced and trained staff, and with the aid of service/troubleshooting manual or manufacturer assistance is available. read more...
In Stock Ships Today
Request a quote for 1336-QPRE-SP1C

Description: The Allen-Bradley 1336-QPRE-SP1C is the pre-charge transistor for the 1336 PLUS/PLUS II/FORCE/IMPACT drives. Specifically, the 1336-QPRE-SP1C is compatible with the following: 7.5 - 15 HP /230V Series C and up PLUS/FORCE/IMPACT drives, 7.5 - 15 HP /230V Series A and up PLUS II drives, 7.5 - 30 HP/460V Series C and up PLUS/FORCE/IMPACT drives and 15-30 HP /460V PLUS II drives. The 1336-QPRE-SP1C pre-charge transistor is available as a spare part for the above-mentioned drives. The presence of dangerously high voltage levels requires that drive repair and maintenance should be executed only by experienced and trained staff, and with the aid of service/troubleshooting manual or manufacturer assistance is available. read more...

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via DHL, UPS, Fedex, and TNT
Repairs: We offer repair service for the 1336-QPRE-SP1C.
Exchange: Exchange credit for your defective unit available.

To speak to a sales representative for pricing & lead time:


Rated 4.5 with 4 reviews

    Technical Specifications for 1336-QPRE-SP1C

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1336-QPRE-SP1C
DescriptionPrecharge Modules
Voltage460V AC
Horsepower7.5-30 HP
Frame ModelsB
Units of Kits per Drive1
Product Lifecycle Status*Discontinued/Obsolete

*The Allen Bradley 1336-QPRE-SP1C has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 1336-QPRE-SP1C units instead of migration.

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1336-QPRE-SP1C
DescriptionPrecharge Modules
Voltage460V AC
Horsepower7.5-30 HP
Frame ModelsB
Units of Kits per Drive1
Product Lifecycle Status*Discontinued/Obsolete

*The Allen Bradley 1336-QPRE-SP1C has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 1336-QPRE-SP1C units instead of migration.

s

About 1336-QPRE-SP1C

The Allen-Bradley 1336-QPRE-SP1C is the pre-charge transistor for the 1336 PLUS/PLUS II/FORCE/IMPACT drives. Specifically, the 1336-QPRE-SP1C is compatible with the following: 7.5 - 15 HP /230V Series C and up PLUS/FORCE/IMPACT drives, 7.5 - 15 HP /230V Series A and up PLUS II drives, 7.5 - 30 HP/460V Series C and up PLUS/FORCE/IMPACT drives and 15-30 HP /460V PLUS II drives. The 1336-QPRE-SP1C pre-charge transistor is available as a spare part for the above-mentioned drives. The presence of dangerously high voltage levels requires that drive repair and maintenance should be executed only by experienced and trained staff, and with the aid of service/troubleshooting manual or manufacturer assistance is available. System power to 1336 PLUS/PLUS II/FORCE/IMPACT drives must be disconnected before the installation/removal of the 1336-QPRE-SP1C.





Furthermore, the drives should only be repaired or serviced after the bus voltage has fallen to 0V. (bus voltage may be observed at +DC/-DC brake terminals). To avoid possible damage to drive parts due to Electro-Static Discharge (ESD), servicing technicians should wear a grounding strap (wrist-type) which is then connected to drive chassis. Any faulty or suspected parts should be placed inside conductive packets immediately after removal from the drives. The 1336 series drives are variable frequency AC drives that are designed for diverse applications and have the following output specifications: 1336 PLUS / PLUS II drives have output ratings of 0.5 to 600 HP (0.37 – 448 kW), 1336 Force series drives have output ratings of 0.75 to 485 kW (1 - 650 HP) and the 1336 IMPACT series drives have output ratings of 0.5 to 800 HP (0.37 - 597 kW).



Technical Description of 1336-QPRE-SP1C

Allen Bradley Precharge Modules with 460V AC output voltage and 7.5-30 HP output power range.

Repair Services for 1336-QPRE-SP1C

Type Lead Time Price Action
Repair Service 2-4 weeks $514.25cartAdd to Cart
Our highly skilled technicians can repair your 1336S-12. All of our repairs come with a 1 Year Warranty. Please contact us for additional information about our repair process.

Revisions for 1336-QPRE-SP1C

Please refer to the manual for more information about the 1336-QPRE-SP1C such as the wiring diagrams, data sheets, firmware information and migration or obsolescence details.

Revision Part # Also Known as Availability
1336-QPRE-SP1C Ser A
1336-QPRE-SP1C/A, Series A, Rev A Request Quote
