Product image is representative; revision or series may vary. Contact us to request a specific version.
160-AA08NSF1
The 160-AA08NSF1 variable speed drive has been designed and manufactured by Allen-Bradley/Rockwell Automation as part of the Bulletin 160 SSC series. It operates with 3-phase or 1-phase AC voltage. The 160-AA08NSF1 variable speed drive is rated for 200 to 240 Volts AC of both 1-phase and 3-phase AC voltage. It comes in an open type of enclosure with an IP 20 environmental protection rating. The 160-AA08NSF1 variable speed drive supports an analog signal follower option.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for 160-AA08NSF1
| Manufacturer | Allen Bradley |
|---|---|
| Product Type | Variable Speed Drive |
| Product Line | 160 SSC Variable Speed Drives |
| Part Number | 160-AA08NSF1 |
| Weight | 2.38 lbs (1.08 kg) |
| Voltage Rating | 200-240V |
| Phase Input | 3 |
| Current Rating | A08 |
| Enclosure Type | Open(IP20) |
| Model Type | Analog Signal Follower |
| Series | C |
| Max. Output Amps | 8 |
| Operational Input Voltage Range | 180-265V AC |
| Input Current | 9.4 |
| Cooling Method | Fan |
| UPC | 10662468599563 |
| Product Lifecycle Status* | Discontinued/Obsolete |
* The Allen Bradley 160-AA08NSF1 has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 160-AA08NSF1 units instead of migration.
The Allen-Bradley 160-AA08NSF1 is an AC Smart Speed Controller (SSC) in the 160 Series which has variable speed and uses an analog signal follower for control. This three-phase controller has an input voltage rating of 200/240V and a 50-60 Hz line frequency. It also has an input kVA of 3.7 and an operational range of 180-265V AC. The output ratings of the 160-AA08NSF1 controller include a maximum output current of 8 A, a power dissipation of 70 W, and 3 phase motor ratings of 2 HP and 1.5 kW. The output voltage of this controller can be adjusted from 0V to its input voltage and it also has a programmable output frequency ranging from 0-240 Hz. Its external speed potentiometer ranges from 1K to 10K Ω, with a minimum of 2 W. Present on the 160-AA08NSF1 controller is a ready/fault indicating panel with LED status indicator lights. It also features 3 terminal blocks for the line power, the motor wiring, and the control wiring. This fan-cooled 160-AA08NSF1 controller has an IP20, open-type enclosure and it should be installed on a flat and vertical surface using mounting screws or a DIN rail mount.
The ambient operating temperature of the 160-AA08NSF1 ranges from 32 to 122 °F, and its non-operating temperature is from -40 to 185 °F. It also has a maximum operating altitude (without derating) of 1000 meters or 3300 feet. and a non-condensing ambient relative humidity range of 0-95%. When operating, the 160-AA08NSF1 controller has an operating vibration of 1 g and an operating shock of 15 g.
| Revision Part # | Also known as | |
|---|---|---|
| 160-AA08NSF1 Ser A | 160-AA08NSF1/A, Series A, Rev A | |
| 160-AA08NSF1 Ser B | 160-AA08NSF1/B, Series B, Rev B | |
| 160-AA08NSF1 Ser C | 160-AA08NSF1/C, Series C, Rev C | |
