160-BA06NSF1P1

The 160-BA06NSF1P1 is a variable speed drive, designed by Allen Bradley with all the standard features of the 160 SSC (Solid Speed Controller) Series. The Allen-Bradley 160-BA06NSF1P1 variable speed drive is a three-phase unit that comes with a rating of 380 to 460 Volts and 2.2KW (3 HP). This drive comes with an open NEMA enclosure, specifically for industrial purposes. It is crucial that users check the type of enclosure required for this module, as the enclosure determines, in part, the main purpose or use of the unit. The Allen-Bradley 160-BA06NSF1P1 variable speed driver should be mounted on a vertical, flat, and level surface. There must be a clearance of at least 12.5 millimeters on all sides of the drive, in order to allow space for the fan work efficiently, while it maintains the ventilation of the unit, and at the same time impedes the unit from heating. The Allen-Bradley 160-BA06NSF1P1 variable speed driver a three-phase unit contains a terminal R (L1) and a PI Control integrated that works through a PI Regulator. This drive is also suitable for direct connection to input power as long as it is connected to the rated voltage. It is recommended that the drive is located as close as possible to the motor in order to prevent a power loss due to the long motor cables. In this case, the main objective is to prevent reflected wave phenomena. In order to change operational parameters, users have to become familiar with the Program Keypad Module Operations.
