2094-XL75S-C2

The 2094-XL75S-C2 line interface module (LIM) is built for industrial applications and it serves as an in input for 230 Volts AC auxiliary power. Generally, the auxiliary power is provided separately and it is not included with the LIM. The LIM module is used with drives from the following drive families: the Kinetix 2000, Kinetix 6200, Kinetix 6500, and the Kinetix 6000 families. The main purpose of the LIM module is to replace the specific input power devices which are typically necessary for the operation of the servo drive system. With the purchase of a module such as the 2094-XL75S-C2 module, the users will eliminate unnecessary wiring and save valuable panel space for other components. The 2094-XL75S-C2 line interface module has an input voltage of 230 to 460 Volts AC and it has a 24 Volts DC rated power output. In addition to that, the current capacity of the module is 20 Amps.

The 2094-XL75S-C2 LIM module does not include configurable branch circuit protection but it does include branch circuit protection and disconnect function. The module also includes features like power to multiple power rails and a DC line filter. The module is compatible with the standard mounting brackets and it requires an external AC line filter. It should be mentioned that this model includes an auxiliary or control power line filter. The current rating of the 2094-XL75S-C2 module is 75 Amps and it has an AC input frequency of 47 to 63 Hertz. The 2094-XL75S-C2 module is connected to 3-phase power sources and it requires a wire size of 14 to 4 AWG. This CE-approved and UL-listed module has an operating temperature range of 0 to 50 degrees Celsius (32 to 122 degrees Fahrenheit) and a storage temperature range of -40 to 70 degrees Celsius (-40 to 158 degrees Fahrenheit).
