Manufactured by Allen-Bradley, the Kinetix 6200 servo drives are designed to bring safety solutions as well as flexible modular or integrated designs to the multi-axis Kinetix 6000 servo drive series. The servo drive axes are well-equipped to provide transition functionalities from the safe-off to safe-speed settings, as well as from the SERCOS interface to the EtherNet/IP network. Besides, the Kinetix 6200 SERCOS interface servo drives are well-matched with the current Kinetix 6000 system, allowing for the upgrade of any number of installed axes as required to reach the advanced safety level. Some of the main features of the Allen-Bradley Kinetix 6200 servo drives are a continuous power output range of 1.2 to 22 kilowatts, an input power voltage range of 324 to 528 Volts AC 3-phase voltage, and a modular design which streamlines the wiring and maintenance, moderates the spare parts catalog, and also helps with quickly adapting to technology enhancements.


Additionally, the Kinetix 6200 servo drives come with safety features including safe direction monitoring, safe stopping, maximum safe speed settings, door monitoring and control, zero speed monitoring, and enabled switch control and safe maximum acceleration monitoring. For enhanced safety, these servo drives allow for reliable access to secure areas as the operation goes on, but under controlled conditions. These drives monitor and reduce the speed of applications to enable the operators to scrutinize and execute a limited amount of work without stopping the machine altogether. The built-in safety features of the Kinetix 6200 servo drives include the safe torque-off feature that prevents the drives from restarting after the tripping of the safety circuit. Also, they come with a secure speed monitor that combines the capability of the safe torque-off and the implanted safety relay with the safe-speed control core technology in a single hardware option set in the drives.

Kinetix 6200 Description Stock Level
2094-BC01-M01-M460 Volt (AC) Voltage Rating, 3.9 kWatts, 9 Amperes Output Current, and Integrated Axis Module
In Stock
2094-BC01-MP5-M460 Volt (AC) Voltage Rating, 3.9 kWatts, 4 Amperes Output Current, and Integrated Axis Module
In Stock
2094-BC02-M02-M460 Volt (AC) Voltage Rating, 6.6 kWatts, 15 Amperes Output Current, and Integrated Axis Module
In Stock
2094-BC04-M03-M460 Volt (AC) Voltage Rating, 13 kWatts, 30 Amperes Output Current, and Integrated Axis Module
Available Now
2094-BC07-M05-M460 Volt (AC) Voltage Rating, 22 kWatts, 45 Amperes Output Current, and Integrated Axis Module
Available Now
2094-BM01-M460 Volt (AC) Voltage Rating, 3.9 kWatts, 9 Amperes Output Current, and Axis Module
In Stock
2094-BM02-M460 Volt (AC) Voltage Rating, 6.6 kWatts, 15 Amperes Output Current, and Axis Module
In Stock
2094-BM03-M460 Volt (AC) Voltage Rating, 13 kWatts, 30 Amperes Output Current, and Axis Module
In Stock
2094-BM05-M460 Volt (AC) Voltage Rating, 22 kWatts, 45 Amperes Output Current, and Axis Module
In Stock
2094-BMP5-M460 Volt (AC) Voltage Rating, 1.8 kWatts, 4 Amperes Output Current, and Axis Module
In Stock
2094-EN02D-M01-S1

The Allen-Bradley 2094-EN02D-M01-S1 module is a safe-speed monitoring control module manufactured as part...

Available Now
2094-SE02F-M00-S0

The 2094-SE02F-M00-S0 control module by Allen-Bradley is available through Bulletin 2094 or Kinetix 6200...

In Stock
2094-SE02F-M00-S1

The 2094-SE02F-M00-S1 control module by Allen-Bradley/Rockwell Automation comes with a Safe Speed Monitor feat...

Available Now
2094-XL75S-C1

The 2094-XL75S-C1 line interface module from the Bulletin 2094 product line is designed by Allen-Bradley. The modu...

Available Now
2094-XL75S-C2

The line interface module (LIM) known as the 2094-XL75S-C2 module is part of the Bulletin 2094 product line a...

In Stock
