Allen Bradley PowerFlex 527 25-ENC-2

Product image is representative; revision or series may vary. Contact us to request a specific version.

25-ENC-2

|
Need a Specific Revision?

The 25-ENC-2 part from Allen Bradley operates as an incremental encoder input module tailored for the PowerFlex 527 series. This device features a voltage DIP switch and an HTL/TTL DIP switch for versatile configuration options.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more
Rockwell Disclaimer: The product is used surplus. DO Supply is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because DO Supply is not an authorized distributor of this product, the Original Manufacturer's warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. DO Supply also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. DO Supply also makes no representations as to your right to install any such firmware on the product. DO Supply will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

Technical specifications for 25-ENC-2

ManufacturerAllen Bradley
CategoryDrives
Product LinePowerFlex 527
Part Number25-ENC-2
UPC887172532160
Weight2.00 lbs (0.91 kg)
ProductIncremental Encoder Input Module
Voltage DIP SwitchIncluded
HTL/TTL DIP SwitchIncluded
Encoder CoverSupported
Compatible DevicePowerFlex 527 Control Module
Minimum Wire Size28 AWG
Maximum Wire Size14 AWG
Wire Torque0.18-0.22 Nm
Voltage24V DC
Request a Repair

The 25-ENC-2 is an incremental encoder input module developed by Allen Bradley within the PowerFlex 527 series. This input module establishes effective communication between an encoder and the control system. It comes equipped with a voltage and HTL/TTL DIP switch, enabling users to adjust settings according to their specific application needs.

The 25-ENC-2 input module supports the installation of an encoder cover, which helps protect connected components from environmental factors. The 25-ENC-2 module is compatible with the PowerFlex 527 control module, making integration seamless and reliable. For wiring, it supports a minimum wire size of 28 AWG and can handle a maximum of 14 AWG, making it versatile for different wiring setups. Proper torque for wires is critical for connection integrity, with a recommended range set between 0.18 and 0.22 Nm. This input module operates efficiently at a nominal voltage of 24V DC, which is ideal for various applications in dynamic environments.
