20AD3PHA3AYNADNN

The 20AD3PHA3AYNADNN is a PowerFlex 70 AC drive manufactured by Allen-Bradley, which is engineered for industrial use and made to be integrated into DeviceNet networks. This device is flexible and it can be configured for a variety of applications. The 20AD3PHA3AYNADNN works with 50 Hertz frequency and it has an input voltage rating of 480 Volts AC, 3-phase. Three-phase supplied motors like this one play a very important role in everyday industrial activity and domestic settings. They move machinery in companies and run basically everything that the users need for manufacturing or other industrial users. To maintain the motor's speed at the desired level, AC drives are implemented. They control motors so that the motor’s speed and torque levels are the ones required by the process.

The Allen-Bradley 20AD3PHA3AYNADNN power output is 1.5 kW and 2.0 Horsepower. It has an A frame size. The module is enclosed in an IP20 NEMA Type 1 enclosure and it is intended for indoor use. It has an interface module (HMI) that makes this device controllable from the point of installation, which can be in the protected areas of the factory and in the automation cabinets. This interface is clearly visible on the front of the drive. It has an LCD and input keys for parameter change and for reading messages. The 20AD3PHA3AYNADNN drive has a fault detection system that will make users aware of the problem through the display and the LEDs. The module is equipped with an internal IGBT option for braking. It supports various modes of operation which are V/Hz control, SVC, and Vector Control with FORCE technology. It ensures electromagnetic filtering, which helps in meeting the CE and EMC requirements. The drive is usually implemented in applications such as fan and pump control.
