20AE041G3AYNANC0

The three-phase Allen-Bradley 20AE041G3AYNANC0 is an AC-powered PowerFlex70 low-voltage manual drive with a full numeric LCD human interface module (HIM), an IGBT brake, an EMC filter, and enhanced control and I/O without a safe-off. This E frame-sized drive has a 600V AC voltage rating, as well as a 41 A, 40 HP, and 30 kW ND rating at an input of 600V, 60 Hz. The HP rating of this drive at normal duty is 40 and it is 30 at heavy-duty, while the output Amps of this drive are 64 A at 3 seconds, 48 A at 1 minute, and 41 A when continuous. The LCD HIM installed on the 20AE041G3AYNANC0 drive consists of a number pad that uses a calculator-like format, control keys made up of direction, speed, start, and stop keys, function keys, and a backlit display that can display up to 21 characters and 7 lines of text. This drive is wall or machine-mounted and has an enclosure rating of NEMA/UL Type 12, IP54, which allows is to operate at rooms temperatures between 0 and 50 °C and be stored at -40 and 70 °C temperatures. Make sure to place the 20AE041G3AYNANC0 in a corrosive-free environment.

Applications suitable for the 20AE041G3AYNANC0 drive include precise torque and speed regulation, closed-loop speed regulation, and open-loop speed regulation. This drive also features three control options for users to choose from, and these are flux vector control, volts per Hertz control, and sensorless vector control. The I/O present on the 20AE041G3AYNANC0 drive are 1 PTC input, 2 analog inputs, 6 digital inputs, 1 analog output, and 2 form C relay outputs.
