Allen Bradley PowerFlex 700 20D-P2-CKE1

Product image is representative; revision or series may vary. Contact us to request a specific version.

20D-P2-CKE1

|
Need a Specific Revision?

The 20D-P2-CKE1 from Allen Bradley is an expanded control cassette designed for the PowerFlex 700 series. This unit allows for the incorporation of additional control capabilities, operating within a temperature range of 0 to 40 °C and able to tolerate storage temperatures up to 65 °C.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more
Rockwell Disclaimer: The product is used surplus. DO Supply is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because DO Supply is not an authorized distributor of this product, the Original Manufacturer's warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. DO Supply also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. DO Supply also makes no representations as to your right to install any such firmware on the product. DO Supply will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

Technical specifications for 20D-P2-CKE1

ManufacturerAllen Bradley
Product TypeExpanded control cassette
Product LinePowerFlex 700
Part Number20D-P2-CKE1
UPC820919741784
Weight2.06 lbs (0.94 kg)
Control TypePhase II
Storage Temperature0–65 °C
Communication Modules SupportedControlNet, DeviceNet, Ethernet/IP
Installation RequirementRequires Phase II control
Cassette Limit per Drive1
Operating Temperature0–40 °C
User Memory1.5 MB
I/O SupportCompact I/O via daughtercard
Mounting TypeInternal
Encoder Voltage Supply11.5 V DC
NetLinx DaughtercardSupported
Non-Volatile Memory1784-CF64 CompactFlash
Tightening Torque0.7 N·m (6 lb-in)
Request a Repair

The 20D-P2-CKE1 expanded control cassette is a vital component for enhancing the functionality of Allen Bradley's PowerFlex 700 drives. This unit is classified under Phase II control and is designed exclusively to work with this specific control type, ensuring compatibility and effective integration. The cassette is optimized to operate in environments with temperatures ranging from 0 to 40 °C while being capable of withstanding storage conditions up to 65 °C.

Designed to house up to one cassette per drive, the expanded control cassette provides essential communication support for multiple protocols, including ControlNet, DeviceNet, and Ethernet/IP. An impressive user memory capacity of 1.5 MB allows for efficient data handling and processing, facilitating smoother operation in automated systems.

This internal mounting solution provides flexibility in assembly while maintaining compact integration within the drive. I/O support is made possible through a daughtercard, enabling the use of compact I/O modules. For encoder connectivity, the cassette supplies 11.5 V DC, ensuring reliable performance.

The 20D-P2-CKE1 also features non-volatile memory through the 1784-CF64 CompactFlash, safeguarding data in case of power loss. The tightening torque specification for assembly is set at 0.7 N·m (6 lb-in), allowing for secure installation without over-tightening. This cassette ultimately enhances the control capabilities of PowerFlex 700 systems.
