The PowerFlex 700 series from Allen-Bradley is a series of adjustable-frequency AC drives designed for the control of 3-phase induction motors in oil well, speed, lifting, and positioning applications. PowerFlex 700 drives provide an economical solution for variable-torque pump and fan applications requiring speed control. The vector control algorithm supported by PowerFlex 700 drives includes Allen-Bradley Force Technology for advanced motor control. Additionally, these drives also support Volts per Hertz and sensorless vector control. PowerFlex 700 drives come in multiple enclosures, including IP 54 wall-mounted, IP 54 flange-mounted, IP 20 NEMA, and zero stacking enclosures. Integrated features such as an internal brake resistor, EMC filtering, and a communication interface enable considerable space conservation.
PC-based software and LCD HMIs can be used for the programming and management of PowerFlex 700 drives. Optional communications adapters for the USB, Ethernet, ControlNet, and DeviceNet networks are available from Allen-Bradley. The input voltage classes for PowerFlex 700 drives and their corresponding power ratings are 0.37 to 66 kilowatts at 200 to 240 Volts, 0.37 to 132 kilowatts at 380 to 480 Volts AC, 1 to 150 Horsepower at 500 to 600 Volts AC, and 45 to 132 kilowatts at 690 Volts AC. A cassette is available for the PowerFlex 700 drives which house all the I/O, control, and encoder options and that can be interchanged with all the PowerFlex 700 drives. The maximum surrounding air temperature (without derating) for open IP 20 rated drives is from 0 to 50 degrees Celsius. The storage temperature for all the enclosure types is from -40 to 70 degrees Celsius.
Browse available units in our catalog of PowerFlex 700.
Featuring an IP20/NEMA Type 1 enclosure, this drive is adequately protected for internal applications. It operates efficiently with a cooling method that relies on air flow. The model supports an I/O
This model features an enclosure type rated IP20, conforming to NEMA 1 standards. It has a frame size of 0 and incorporates an IGBT brake while lacking an internal brake feature. There are no communic
This device is designed for 3-phase systems and functions with a frequency rating of 60 Hz. It features an IP20 protection category and is suitable for operation in humidity levels of up to 80% (witho
This AC drive supports a control method based on vector control and includes a common mode choke. It allows for a 24V DC/AC I/O voltage. The design features an IP20/NEMA Type 1 enclosure rating for ad
The 20BD3P4A3AYYANC0 is categorized as an adjustable frequency AC drive designed for efficient control in industrial contexts. It provides a rated power of 2 horsepower and operates at a frequency of
The part 20BD065A3AYNAND0 is an adjustable frequency AC drive designed for three-phase systems with a rated voltage of 480 VAC. It handles an input current of 65 A and operates at an input frequency o
This adjustable frequency drive supports vector control with DPI and has an I/O voltage rating of 24V DC. It includes both an emissions filter and emissions choke, enhancing its operational efficiency
This adjustable frequency drive features a blank cover for the HMI option, maintaining a streamlined design. It operates at 480 volts with a frame size classified as 3. The unit incorporates an IGBT f
This model is intended for use in controlled indoor environments. It has an overcurrent trip function set at 200% of the rated current, enhancing its protective features. The drive is equipped with a
This Logix expansion board is classified for integrated control operation and utilizes a screw mounting method. It is an internal printed circuit board compatible exclusively with the DriveLogix 5730.
