The PowerFlex 700 series from Allen-Bradley is a series of adjustable-frequency AC drives designed for the control of 3-phase induction motors in oil well, speed, lifting, and positioning applications. PowerFlex 700 drives provide an economical solution for variable-torque pump and fan applications requiring speed control. The vector control algorithm supported by PowerFlex 700 drives includes Allen-Bradley Force Technology for advanced motor control. Additionally, these drives also support Volts per Hertz and sensorless vector control. PowerFlex 700 drives come in multiple enclosures, including IP 54 wall-mounted, IP 54 flange-mounted, IP 20 NEMA, and zero stacking enclosures. Integrated features such as an internal brake resistor, EMC filtering, and a communication interface enable considerable space conservation.
PC-based software and LCD HMIs can be used for the programming and management of PowerFlex 700 drives. Optional communications adapters for the USB, Ethernet, ControlNet, and DeviceNet networks are available from Allen-Bradley. The input voltage classes for PowerFlex 700 drives and their corresponding power ratings are 0.37 to 66 kilowatts at 200 to 240 Volts, 0.37 to 132 kilowatts at 380 to 480 Volts AC, 1 to 150 Horsepower at 500 to 600 Volts AC, and 45 to 132 kilowatts at 690 Volts AC. A cassette is available for the PowerFlex 700 drives which house all the I/O, control, and encoder options and that can be interchanged with all the PowerFlex 700 drives. The maximum surrounding air temperature (without derating) for open IP 20 rated drives is from 0 to 50 degrees Celsius. The storage temperature for all the enclosure types is from -40 to 70 degrees Celsius.
Browse available units in our catalog of PowerFlex 700.
This drive is designed to withstand line transients of up to 6000 volts peak, ensuring reliability in fluctuating electrical environments. Its construction adheres to NEMA Type 1 and UL Type 1 standar
With a current rating of 2.1 A, this 3-phase unit is designed to function within an operating temperature range of 0°C to 40°C. It has a maximum operating humidity of 95% without condensation and incl
This adjustable frequency drive supports a nominal current rating of 41 A and provides up to 40 horsepower, equating to 30 kW of power output. It is categorized as size 3 and features protection ratin
This model supports 3-phase operations and offers vector control functionality. It is equipped with a full numeric keypad and an LCD display for easy user interaction. The drive also allows for 24 V D
This AC drive functions at a rated frequency of 60 Hz and is designed for 3-phase applications. The operational temperature range is between 0°C and 40°C, and it can withstand humidity levels up to 95
The SK-G9-FAN2-F5 is a heat sink fan kit designed for the PowerFlex 700 series. Operating at a voltage class of 208/240 V AC, this component contributes to an effective cooling system. It is compact i
This adjustable frequency AC drive is built for 3-phase applications and operates efficiently within a temperature range from 0°C to 40°C. The 20BC260A0ANNANC0 is designed for an operating altitude of
This unit features IP20 rated enclosure conforming to NEMA/UL Type 1 standards, offering protection suitable for indoor environments. The operator interface includes an LCD display complemented by a f
This drive features an IP20 enclosure designated as NEMA/UL Type 1 and supports a control type of vector. It also includes emission compliance through an integrated CE filter and common mode choke. Th
The 20BD156A0AYNAND0 is an adjustable frequency AC drive that operates at a voltage rating of 480 volts AC, suitable for 3-phase power inputs. With a motor power capacity of 125 horsepower, this devic
