The 9101-1631 The Allen-Bradley 1398 Servo Drive 1398-DDM-075X has 100-240 rms Volts Nominal (Single or Three Phase) AC Input Voltage, 47-63 Hz AC Input Frequency, 30 amps rms AC Input Current, and 141-339 Volts (DC) Bus Voltage.
