The 9101-1812 The Allen-Bradley 1398 Servo Drive 1398-DDM-019X-DN has 100-240 Vac rms Nominal (Single Phase) AC Input Voltage, 47-63 Hz AC Input Frequency, 18 amps rms AC Input Current, and 141-339 Volts (DC) Bus Voltage.
Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via DHL, UPS, Fedex, and TNT
Repairs: We offer repair service for the 9101-1812.
Exchange: Exchange credit for your defective unit available.
