9101-2196

The Allen-Bradley 9101-2196 is an Ultra Plus operator terminal that is especially designed for use with the 1398 Ultra Plus Series Positioning module. The 9101-2196 is the alternative part number for the 1398-HMI-002.

The 9101-2196 is designed with a Vacuum Fluorescent display that is capable of displaying Four (4) lines of Twenty (20) characters with each character measuring 5 mm high. It is powered by an external supply voltage of 110/240 VAC ±15% with integrated RS232 communication port with power consumption of 25 Watts.

The Graphical Motion Language (GML) supports the Flow Chart programming language where diagram and states are mostly presented by blocks.

The 9101-2196 has numeric keys, programmable keypads with tactile feedback. The keypad is composed of X1-X4, Function Keys composed of F1-F4, navigation and confirmation buttons. Up to Twenty-Four (24) predefined functions including selecting and running a program, jog operation and stopping a program.

The 9101-2196 has an operating temperature requirement of 32° to 131°F (0° to 55°C) ambient and storage temperature of -40° to 158°F (-40° to 70°C) ambient. The relative humidity is 5% to 95% non-condensing. This operator terminal is designed to be installed in an enclosure rated NEMA 4 (IP64) and NEMA 12 (IP66). The built-in RS232 interface may be used with the 9101-2205 communication cable. The 9101-2196 has physical dimensions of 152.4 mm (H) x 266.7 mm (W). It requires a cutout template of 129.5 mm (H) x 243.8 mm (W).

The Allen-Bradley 9101-2196 operator terminal features a NEMA 4/12 front panel seal, which protects the terminal from external particles that could represent a treat for its proper functioning. This enclosure offers protection against dust particles and liquids dropping and it is intended for general purpose use. The operating environmental conditions for the Allen-Bradley 9101-2196 operator terminal are a temperature of 0 to 55 degrees Celsius and a non-condensing humidity of 5 to 95%. When it comes to storage, the recommended temperature range goes from -40 to 70 degrees Celsius, and a non-condensing humidity of 5 to 95%. The Allen-Bradley 9101-2196 operator terminal features a vacuum fluorescent display with four lines and twenty characters per line of display space. Each character has a height of 5 millimeters. This terminal requires an RS-232 cable, which is also manufactured by Allen-Bradley under the code 9101-2205. This terminal also has a built-in keyboard that includes numeric, function, and programmable keys. This terminal has an approximate shipping weight of 3 kilograms (equivalent to 7 pounds).
