The Allen Bradley 194R switches series is a series of fused and non-fused rotary disconnect switches. Their current ratings range from 20 to 1250 Amps. Some of the non-fused 194R switches are IEC rotary switches. All of the switches support panel mounting and some also support DIN Rail mounting. The rated voltage for the 194R switches is 690V AC, and the short circuit rating for the switches is 200 kA. Up to 6 auxiliary contacts can be added to the 194R switches.
Browse available units in our catalog of 194R Switches.
This switch features a robust NEMA enclosure classified as type 3/4/12 with an IP66 rating, offering extensive protection against dust and water ingress. It is rated for short circuit withstands of 20
This fused disconnect switch is constructed for 3-pole configurations and is mounted on a DIN rail. It operates within a frequency rating of 50/60 Hz, offers a maximum short-circuit rating of 100 kA,
This module accommodates four poles and supports a voltage rating of up to 600 V AC. It is compatible with UL Class J and CSA HRCI-J fuses and meets applicable UL and CSA safety standards. The connect
This rotary handle is ideal for non-fused applications and supports up to 1200A. It comes with a door interlock complying with NFPA standards and can accommodate up to three padlocks in the OFF positi
This model supports a maximum of eight auxiliary circuits and is rated for a mechanical endurance of 10,000 operations. It accommodates significant horsepower ratings, including 2 HP at 115 VAC, 20 HP
Rated for 400 amps, this terminal lug kit accepts two 350 kcmil (MCM) cables. The device operates efficiently in a temperature range from -20 °C to 60 °C and can be stored safely between -40 °C and 65
Designed as a manual operation switch handle, this model is constructed with a plastic round handle. It encompasses NFPA standards for safety and features universal internal mounting. The kit includes
This non-fusible disconnect switch supports 600 V AC with a short-circuit withstand capacity of 200 kA. Its rated motor capacity is 7.5 HP, and it is suitable for wire sizes ranging from AWG 14 to AWG
Designed for compatibility within the 194R switch series, the 194R-HM4E operates under various conditions. It has a protective IP66 rating, safeguarding against dust and water exposure. The handle is
This internal handle features a quarter-turn rotation, ensuring efficient operation. It has a metal construction with a black finish and a shaft length measuring 320 mm (10.6 in). The handle complies
