Compact and high-performance, the Allen Bradley 700-H relays are designed for general purpose and industrial rotary use. These high-performance relays provide a reliable switch for low-power circuits and signal-level circuits for efficient operation in automation systems. The relays' flexible configuration options enable the user to select specific relay models according to different voltage and load requirements. The 700H series relays enhance control system reliability with rugged construction and trouble-free performance.
Browse available units in our catalog of 700-H Relays.
This square base relay supports a coil voltage of 240 VAC and is designed to work within a frequency range of 50 to 60 Hz. It can handle switching voltages of 250 VAC for AC and 30 VDC for DC applicat
This relay features DPDT timed contacts and offers a timing range from 0.05 seconds to 12 minutes. It can handle a nominal contact current of 5 Amps and has a contact make capacity of up to 30 Amps. T
This relay supports a switching current of 10A and offers a switching voltage of 240 VAC or 30 VDC. Its terminals utilize a screw connection for easy installation. The contact material is silver nicke
Featuring two changeover contacts, this slim line relay is rated for a nominal current of 8 Amps. The relay operates at a supply voltage of 24 VDC and connects via a plug-in method. With an IP20 prote
Designed with a contact configuration of SPDT, this relay supports frequencies from 50 Hz to 60 Hz. It features a pilot light option and is constructed with silver nickel contacts for enhanced durabil
This square base relay features a frequency range of 50 to 60 Hz, with a 3PDT contact arrangement. The contact material is made of silver cadmium oxide, ensuring reliability. It has an IP40 rating for
This general-purpose relay operates efficiently at a control supply voltage of 120 V AC, capable of handling a nominal current of 8 A. It features two change-over contacts and a plug-in electrical con
This relay features a rated current of 2A and a peak blocking voltage of 33 Vp. It has a pickup voltage of 19 V and a dropout voltage of 9.6 V. The maximum leakage current is measured at 0.1 mA. Overa
This relay enables switching at a maximum current of 10 A. The AC switching voltage is rated at 240 VAC, while the DC switching voltage can reach up to 30 VDC. The relay operates within a coil resista
This relay socket is specified with a touch-safe terminal construction, enhancing user safety during operation. It is designed to function within a temperature range of -40°C to 70°C, making it suitab
