Allen Bradley 800H Push Buttons

The Allen Bradley 800H push buttons are 30 mm push buttons that can be used in a wide range of industrial control applications, and they are designed to be durable. The 800H series includes push buttons with a range of colors, contact options, illumination options, and other features that users can select from. Color options for 800H push buttons include red, green, black, blue, gray, orange, and white. Some 800H Push Buttons models are available with legend caps that identify the push button and its functions. These push button models include models with green caps that have the legend "start" printed on them in white letters, and models with red caps that have the legend "stop" printed on them in white letters. Many 800H push buttons are made of durable Type 4/4X/13 plastic. Push buttons with contact configurations of 1 N.C., 1 N.O., or 1 N.C. and 1 N.O. are available in the 800H push buttons series. Some 800H push buttons are illuminated with either universal or transformer LEDs. The 800H push buttons are available with flush heads or with extended heads.

The Allen Bradley 800H push buttons can support vibration ratings of 10 to 2000 Hz and 0.06 inches of displacement/10 G peak-to-peak (except for the logic reed). The shock ratings of the 800H push buttons include 25 g for 11 ms (contact fragility) and up to 100 g with no damage. Some 800H push buttons have minimum mechanical lifespan ratings of 10,000,000 mechanical design lifecycles or actuations. Different models support different typical operating force ratings. The 800H push buttons that are non-illuminated and have no contact blocks support typical operating force ratings of 2 pounds maximum. The 800H push buttons that are illuminated have typical operating force ratings of 5 pounds maximum. The 800H push buttons typically support wires with gauges of #18 to 14 AWG, but some push buttons can support MaxDuty wire gauges of #18 to 10 AWG. These push buttons can operate at temperatures of -13 to 104 degrees Fahrenheit and be stored at temperatures of -40 to 185 degrees Fahrenheit. The components in the 800H push buttons are made of different types of plastic. The sockets, bushings, mounting rings, and non-illuminated caps are made of polyester, while the trim washers, thrust washers, and illuminated caps are made of nylon.
