1203-FM1

1203-FM1

Description:

The Allen-Bradley/Rockwell Automation 1203-FM1 module is a specialized Flex I/O SCANport module. It can be removed and inserted under power, but it can only be installed on a special 1203 terminal base unit. This module operates with 5 Volts of input voltage from the Flexbus adapter.

Rated 4.4 with 13 reviews
top legal disclaimer
top legal disclaimer

credit cards accepted
better business bureau

In Stock Ships Today

Submit RFQ for 1203-FM1

Add more parts to quote

Description:

The Allen-Bradley/Rockwell Automation 1203-FM1 module is a specialized Flex I/O SCANport module. It can be removed and inserted under power, but it can only be installed on a special 1203 terminal base unit. This module operates with 5 Volts of input voltage from the Flexbus adapter.



Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via DHL, UPS, Fedex, and TNT
Repairs: We offer repair service for the 1203-FM1.
Exchange: Exchange credit for your defective unit available.

To speak to a sales representative for pricing & lead time:


Rated 4.4 with 13 reviews

    Technical Specifications for 1203-FM1

ManufacturerAllen-Bradley/Rockwell Automation
Series1203 Communication Modules
Part Number1203-FM1
Product TypeSCANport Module
Removal and Insertion Under PowerSupported
Mounting1203 Terminal Base Unit
Input Voltage5 Volts
Dimensions1.8 x 3.7 x 2.1 inches
Operating Temperature32 to 140 degrees Fahrenheit
Storage Temperature-40 to 185 degrees Fahrenheit
ManufacturerAllen-Bradley/Rockwell Automation
Series1203 Communication Modules
Part Number1203-FM1
Product TypeSCANport Module
Removal and Insertion Under PowerSupported
Mounting1203 Terminal Base Unit
Input Voltage5 Volts
Dimensions1.8 x 3.7 x 2.1 inches
Operating Temperature32 to 140 degrees Fahrenheit
Storage Temperature-40 to 185 degrees Fahrenheit
s

About 1203-FM1

The 1203-FM1 module is a Flex I/O SCANport module from Allen-Bradley/Rockwell Automation. It is designed to be mounted on a special Allen-Bradley 1203 series terminal base unit, and only on this particular terminal base unit. It cannot and should not be used with any other type of flex base. The 1203-FM1 SCANport module can be removed or inserted under power safely, but note that removing it under power may cause the SCANport devices that are attached to it to experience faults. To install the 1203-FM1 SCANport module with or without applied power, rotate the keyswitch on the 1203 terminal base unit clockwise to position 1, make sure that the flexbus connector is pushed all the way to the left to connect to the neighboring terminal base, make sure the pins on the bottom of the module are all straight, position the module by using its alignment bare, and press the module firmly down into place until the latching mechanism of the terminal base is locked into the module.







The Allen-Bradley/Rockwell Automation 1203-FM1 Flex I/O SCANport module sometimes requires twice as much adapter power supply current as standard flex modules do, and this limits the number of standard modules and the number of modules like the 1203-FM1 SCANport module that can be installed in the same system. Up to 4 1203-FM1 Flex I/O SCANport modules can be used with the same flex adapter at a time. This module's input voltage rating is 5 Volts from the Flexbus adapter. Its dimensions are 1.8 x 3.7 x 2.1 inches, its operating temperature range is 32 to 140 degrees Fahrenheit at 5 to 80% non-condensing relative humidity, and its storage temperature range is -40 to 185 degrees Fahrenheit at 5 to 95% non-condensing relative humidity.



Repair Services for 1203-FM1

Type Lead Time Price Action
Repair Service 2-4 weeks $125.09cartAdd to Cart

Our highly skilled technicians can repair your 1203-FM1. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Dimensions For 1203-FM1

Size
Input Type
Panel Cutout Height in mm
Panel Cutout Width in mm
Terminal Height in mm
Terminal Width in mm
Terminal Overall Depth in mm
Terminal Mounted Depth in mm

Dimensions For 1203-FM1

Resolutions For 1203-FM1

About

Technical Specifications for 1203-FM1

ManufacturerAllen-Bradley/Rockwell Automation
Series1203 Communication Modules
Part Number1203-FM1
Product TypeSCANport Module
Removal and Insertion Under PowerSupported
Mounting1203 Terminal Base Unit
Input Voltage5 Volts
Dimensions1.8 x 3.7 x 2.1 inches
Operating Temperature32 to 140 degrees Fahrenheit
Storage Temperature-40 to 185 degrees Fahrenheit
ManufacturerAllen-Bradley/Rockwell Automation
Series1203 Communication Modules
Part Number1203-FM1
Product TypeSCANport Module
Removal and Insertion Under PowerSupported
Mounting1203 Terminal Base Unit
Input Voltage5 Volts
Dimensions1.8 x 3.7 x 2.1 inches
Operating Temperature32 to 140 degrees Fahrenheit
Storage Temperature-40 to 185 degrees Fahrenheit

About 1203-FM1

The 1203-FM1 module is a Flex I/O SCANport module from Allen-Bradley/Rockwell Automation. It is designed to be mounted on a special Allen-Bradley 1203 series terminal base unit, and only on this particular terminal base unit. It cannot and should not be used with any other type of flex base. The 1203-FM1 SCANport module can be removed or inserted under power safely, but note that removing it under power may cause the SCANport devices that are attached to it to experience faults. To install the 1203-FM1 SCANport module with or without applied power, rotate the keyswitch on the 1203 terminal base unit clockwise to position 1, make sure that the flexbus connector is pushed all the way to the left to connect to the neighboring terminal base, make sure the pins on the bottom of the module are all straight, position the module by using its alignment bare, and press the module firmly down into place until the latching mechanism of the terminal base is locked into the module.







The Allen-Bradley/Rockwell Automation 1203-FM1 Flex I/O SCANport module sometimes requires twice as much adapter power supply current as standard flex modules do, and this limits the number of standard modules and the number of modules like the 1203-FM1 SCANport module that can be installed in the same system. Up to 4 1203-FM1 Flex I/O SCANport modules can be used with the same flex adapter at a time. This module's input voltage rating is 5 Volts from the Flexbus adapter. Its dimensions are 1.8 x 3.7 x 2.1 inches, its operating temperature range is 32 to 140 degrees Fahrenheit at 5 to 80% non-condensing relative humidity, and its storage temperature range is -40 to 185 degrees Fahrenheit at 5 to 95% non-condensing relative humidity.



Repairs
Type Lead Time Price Action
Repair Service 2-4 weeks $125.09cartAdd to Cart

Our highly skilled technicians can repair your 1203-FM1. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Type Lead Time Price Action
Repair Service 2-4 weeks $125.09cartAdd to Cart

Our highly skilled technicians can repair your 1203-FM1. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.
