2080-IQ4OV4

Revisions: Ser A
Description: This Micro 800 Programmable Logic Controller is a 4-ch Digital Input/Output combination module.
Available Now
Request a quote for 2080-IQ4OV4

Description: This Micro 800 Programmable Logic Controller is a 4-ch Digital Input/Output combination module.

top legal disclaimer
disclaimer
credit cards
better business bureau
Revisions: Ser A

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via DHL, UPS, Fedex, and TNT
Repairs: We offer repair service for the 2080-IQ4OV4.
Exchange: Exchange credit for your defective unit available.

To Speak to a sales representative for pricing & lead time:

phone

International
919-205-4392

Rated 4.4 with 11 reviews

    Technical Specifications for 2080-IQ4OV4

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.2080-IQ4OV4
Product TypeDigital Plug-in Module
DC On-state Voltage min./max.9.0/30V DC
DC On-state Current min.2.0 mA @ 9V DC
DC On-state Current nom.3.0 mA @ 24V DC
DC On-state Current max.5.0 mA
DC Off-state Voltage max.5V DC
DC Off-state Current max.1.5 mA
IEC Input Compatibility Type 3
AC On-state Voltage min./max.10.25V AC/30V AC
AC On-state Current min./max.2mA @ 9V AC/ 5.0 mA
Enclosure Type RatingNone(open-style)
Sinking Output Power Supply Voltage min./max.10.8V DC/30V DC
Sinking Output On-state Voltage min./nom./max.10V DC/24V DC/30V DC
Sinking Output On-state Current min./max.5.0mA @ 10V DC/ 0.5 A
ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.2080-IQ4OV4
Product TypeDigital Plug-in Module
DC On-state Voltage min./max.9.0/30V DC
DC On-state Current min.2.0 mA @ 9V DC
DC On-state Current nom.3.0 mA @ 24V DC
DC On-state Current max.5.0 mA
DC Off-state Voltage max.5V DC
DC Off-state Current max.1.5 mA
IEC Input Compatibility Type 3
AC On-state Voltage min./max.10.25V AC/30V AC
AC On-state Current min./max.2mA @ 9V AC/ 5.0 mA
Enclosure Type RatingNone(open-style)
Sinking Output Power Supply Voltage min./max.10.8V DC/30V DC
Sinking Output On-state Voltage min./nom./max.10V DC/24V DC/30V DC
Sinking Output On-state Current min./max.5.0mA @ 10V DC/ 0.5 A
s

About 2080-IQ4OV4

The Allen-Bradley 2080-IQ4OV4 is a Micro800 digital plug-in module manufactured by Rockwell Automation that can work with Allen-Bradley’s Micro820, Micro830, and Micro850 controllers and it features 12-pin female terminal blocks. This combination module has 8 points available, specifically 4 12/24V DC sink/source inputs and 4 12/24V DC sink outputs. In an on-state, the 2080-IQ4OV4 module’s input has a DC voltage that ranges from 9-30V DC, as well as a DC current that ranges from 2-5 mA and it has a nominal DC current of 3 mA at 24V DC. Its highest off-state DC voltage is 5V DC and its highest off-state DC current is 1.5 mA. The AC on-state voltage of the 2080-IQ4OV4 module runs from a minimum of 10.25V AC rms to a maximum of 30V AC rms, while its AC on-state current runs from 2 mA at 9V AC rms to 5 mA.



The minimum power supply voltage of this module is 10.8V DC and its maximum is 30V DC. The on-state power supply voltage is from a minimum of 10V DC to a maximum of 30V DC, with a nominal of 24V DC. Its minimum on-state power supply current is 5 mA at 10V DC at a minimum and 0.5 A at maximum in a steady state.



The 2080-IQ4OV4 module has an open-type enclosure and it is equipped with 8 yellow status indicators. Its operating temperature is -20-65 oC and its storage temperature is -40-85 oC. The maximum ambient air temperature is 65 oC, while its ambient non-condensing humidity range is from 5-95%.

Repair Services for 2080-IQ4OV4

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your 2080-IQ4OV4. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions for 2080-IQ4OV4

Please refer to the manual for more information about the 2080-IQ4OV4 such as the wiring diagrams, data sheets, firmware information and migration or obsolescence details.

Revision Part # Also Known as Availability
2080-IQ4OV4 Ser A
2080-IQ4OV4/A, Series A, Rev A Request Quote
