1762-IQ16

Revisions: Ser A Ser B
Description: The 1762-IQ16 is an Allen-Bradley MicroLogix module with Sixteen (16) 24VDC channel input module. This input module is suitable expansion module for MicroLogix 1100 / 1200 / 1400 Programmable Logic Controllers (PLC).
In Stock Ships Today
Request a quote for 1762-IQ16

Description: The 1762-IQ16 is an Allen-Bradley MicroLogix module with Sixteen (16) 24VDC channel input module. This input module is suitable expansion module for MicroLogix 1100 / 1200 / 1400 Programmable Logic Controllers (PLC).

DO Supply is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with DO Supply's 1-year warranty

Rockwell Disclaimer: The product is used surplus. DO Supply is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because DO Supply is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. DO Supply also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. DO Supply also makes no representations as to your right to install any such firmware on the product. DO Supply will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

disclaimer
credit cards
better business bureau
Revisions: Ser A Ser B

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via UPS, DHL, and TNT
Repairs: We offer repair service for the 1762-IQ16.
Exchange: Exchange credit for your defective unit available.
Conditions: We sell preowned surplus and refurbished parts.

To speak to a sales representative for pricing & lead time:


Rated 4.9 with 11 reviews

    Technical Specifications for 1762-IQ16

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1762-IQ16
Product FamilyMicroLogix
Compatible ControllersMicroLogix 1100, 1200 and 1400
Outputs10 to 30 Volts DC
Inputs(16) Sinking and Sourcing Inputs
Product TypeDiscrete Input Module
Commons2
SeriesA and B
Input Power24 Volts DC
SeriesA and B
Operating Voltage Range10…30V DC; 10…26.4V DC
Signal Delay8.0 ms
Off-State voltage, max5V DC
Off-State current, max1.5 mA
UPC10611320152132
On-State voltage, min10V DC
On-State Current, max2.0 mA min @ 10V DC; 8.0 mA nom @ 24V DC; 12.0 mA max @ 30V DC;
Dimensions3.54 x 1.59 x 3.43 in (HxWxD)
Enclosure RatingIP20
ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1762-IQ16
Product FamilyMicroLogix
Compatible ControllersMicroLogix 1100, 1200 and 1400
Outputs10 to 30 Volts DC
Inputs(16) Sinking and Sourcing Inputs
Product TypeDiscrete Input Module
Commons2
SeriesA and B
Input Power24 Volts DC
SeriesA and B
Operating Voltage Range10…30V DC; 10…26.4V DC
Signal Delay8.0 ms
Off-State voltage, max5V DC
Off-State current, max1.5 mA
UPC10611320152132
On-State voltage, min10V DC
On-State Current, max2.0 mA min @ 10V DC; 8.0 mA nom @ 24V DC; 12.0 mA max @ 30V DC;
Dimensions3.54 x 1.59 x 3.43 in (HxWxD)
Enclosure RatingIP20
s

About 1762-IQ16

The Allen-Bradley 1762-IQ16 is a 16-point sink and source input module. It measures 90 x 87 x 40 millimeters, runs on 24 Volts DC input power at a 10 to 30 Volt DC operating voltage. Its maximum heat dissipation is 3.7 Watts. The 1762-IQ16 enhances the functionality of MicroLogix 1100, 1200, and 1400 controllers. It needs minimal space and it can be mounted on a DIN rail or a panel mount. The 1762-IQ16 module is a sinking and sourcing module that regulates the current flow between the input module and the connected device. The devices on the negative side of the module are sinking field devices and the ones on the positive side are sourcing field devices. The Source devices always provide current to the Sink devices. The 1762-IQ16 module has a single status LED that indicates power and helps identify the source of all the problems. The module communicates and receives 10, 24, and 30 Volts of DC power via the 1762 bus interface. For wiring the input terminal blocks, a finger-safe cover is included. The 1762-IQ16 uses bit positions 0 to 15 of word 0 for the input terminals. The operation details of the module must be configured for each channel after installation.

While troubleshooting, always keep a safe distance away from the equipment and always check for any changes in the program. The safety circuits should always be wired to the master relay in series. The 1762-IQ16 module should be installed in non-hazardous, dry, and clean environments with circuits that do not exceed Overvoltage Category II Standards. To avoid damaging the 1762-IQ16, take precautions to avoid electrostatic discharge and remove all power before performing any maintenance tasks. The 1762-IQ16 is an Allen-Bradley MicroLogix DC Input Module. The 1762-IQ16 is a 16-point sink/source input module with an input voltage rating of 24 Volts DC. This module has both DIN rail and Panel mounting options.

The Allen-Bradley 1762-IQ16 is a Sixteen (16) channel discrete input module that is used with MicroLogix 1100, 1200 and 1400 Programmable Logic Controllers. This PLC features a compact form wherein minimum hardware requirements to operate as a PLC are integrated such as Power Supply, Input and Output, Communication ports and Memory.

Depending on the MicroLogix controller used, expansion module support varies. If the 1762-Q16 is used with MicroLogix 1100, up to Four (4) expansion modules may be used. If used with MicroLogix 1200, up to Six (6) modules may be used. For MicroLogix 1400, up to Seven (7) 17620IQ16 may be used. Expansion modules are not exclusive for 1762-IQ16 only. Expansion modules may be a mix of any module in the MicroLogix family.

The 1762-IQ16 features Sixteen (16) sinking and sourcing capable channels. Each channel may be wired to a field input device carrying a nominal voltage of 24VDC. Each channel exhibits signal delay of 8.0 ms for both ON to OFF and OFF to ON transition. These input channels are ideal for interfacing field devices such as limit switches, relay and magnetic contactor contacts, proximity sensors and other discrete devices.

This data file contains the Input information which may be represented in binary, octal, decimal and Hexadecimal values. These representations are called Radix.

To connect this module to the MicroLogix base controller, simply interconnect the provided ribbon cable to the assigned slot in the adjacent module. The ribbon cable establishes the bus connection as well as provide power distribution.

FAQ for 1762-IQ16

What type of input does this module have?


The 1762-IQ16 has 16 Sink/Source inputs.

How many I/O modules, such as the 1762-IQ16, can I connect to my MicroLogix Controller?


The maximum number of I/O modules, such as the 1762-IQ16, that can connect to a MicroLogix Controller at once depends on the controller. MicroLogix 1100 Controllers can support up to 4 I/O modules, MicroLogix 1200 Controllers can support up to 6 I/O modules and MicroLogix 1400 Controllers can support up to 7 I/O modules.

Can this module be purchased with a warranty?


Yes, the 1762-IQ16 comes with a free one-year warranty from DO Supply, Inc.

Where can I send the 1762-IQ16 to be repaired?


DO Supply, Inc. offers a variety of repair services for the 1762-IQ16.

Technical Description of 1762-IQ16

The 1762-IQ16 is a MicroLogix 1200 Allen Bradley module. It is a Sink/Source Input Module. The 1762-IQ16 has an IP20 rated Enclosure. It has an output voltage of 10 to 30 Volts DC.

Repair Services for 1762-IQ16

Type Lead Time Price Action
Repair Service 2-4 weeks $460cartAdd to Cart

Our highly skilled technicians can repair your 1762-IQ16. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions for 1762-IQ16

Please refer to the manual for more information about the 1762-IQ16 such as the wiring diagrams, data sheets and migration or obsolescence details.

Revision Part # Also Known as Availability
1762-IQ16 Ser A
1762-IQ16/A, Series A, Rev A Request Quote
1762-IQ16 Ser B
