1766-L32BXB

Revisions: Ser A Ser B Ser C
Description: The 1766-L32BXB is a MicroLogix 1400 Controller under the Bulletin 1766 product family. This compact controller features integrated Three (3) communication ports such as a combo RS232 / RS485 port, isolated RS232 port and an Ethernet communication port. It has embedded Input and Output channels which consists of Twelve (12) Fast 24VDC, Eight (8) Normal 24VDC, Six (6) Relay, Three (3) Fast DC and Three (3) Normal DC outpts. This controller is configured and programmed with RSLogix 500 / RSLogix 500 Micro programming software.
In Stock Ships Today
Request a quote for 1766-L32BXB

Description: The 1766-L32BXB is a MicroLogix 1400 Controller under the Bulletin 1766 product family. This compact controller features integrated Three (3) communication ports such as a combo RS232 / RS485 port, isolated RS232 port and an Ethernet communication port. It has embedded Input and Output channels which consists of Twelve (12) Fast 24VDC, Eight (8) Normal 24VDC, Six (6) Relay, Three (3) Fast DC and Three (3) Normal DC outpts. This controller is configured and programmed with RSLogix 500 / RSLogix 500 Micro programming software.

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via DHL, UPS, Fedex, and TNT
Repairs: We offer repair service for the 1766-L32BXB.
Exchange: Exchange credit for your defective unit available.

To speak to a sales representative for pricing & lead time:


Rated 4.4 with 5 reviews

    Technical Specifications for 1766-L32BXB

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1766-L32BXB
Module TypeController
Product Family:MicroLogix
SeriesMicroLogix 1400
Product Type:MicroLogix 1400 Controller
Inputs(12) Digital Fast 24V DC, (8) Digital Normal 24V DC, (2) Analog
Part Number:1766-L32BWA
Outputs(6) Relay, (3) Fast 24V DC, (3) Normal 24V DC
Number of I/O:32 points
Operating Power24V DC
Number of Discrete Inputs:Twelve (12) Fast 24VDC; Eight (8) Normal 24VDC
Channel Count(20) IP, (12) OP
Analog Input Signal Range:None
Memory20 KB
Number of Discrete Outputs:Six (6) Relay; Three (3) Fast DC; Three (3) Normal DC
FeatureBuilt-in RTC
CommunicationEthernet/IP
Operating Frequency:47-63 Hz
UPC10612598518118
Power Consumption:50W; 7.5W (with no 1762 expansion I/O)
Power supply inrush current24V DC: 15 A for 20 ms
Communication port:1 RS232 / RS485; 1 Ethernet; 1 RS232
Supported Protocols:Serial: DF1, ASCII, MODBUS RTU, DNP3, DH485 Ethernet: Ethernet I/P, DNP3, MODBUS TCP/IP
Programming Software:RSLogix 500; RSLogix 500 Micro
Shipping weight:2 lbs
Dimensions:90 x 180 x 87 mm (3.5 x 7.087 x 3.43 in)
Mounting:Panel Mounting / DIN Rail
ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1766-L32BXB
Module TypeController
Product Family:MicroLogix
SeriesMicroLogix 1400
Product Type:MicroLogix 1400 Controller
Inputs(12) Digital Fast 24V DC, (8) Digital Normal 24V DC, (2) Analog
Part Number:1766-L32BWA
Outputs(6) Relay, (3) Fast 24V DC, (3) Normal 24V DC
Number of I/O:32 points
Operating Power24V DC
Number of Discrete Inputs:Twelve (12) Fast 24VDC; Eight (8) Normal 24VDC
Channel Count(20) IP, (12) OP
Analog Input Signal Range:None
Memory20 KB
Number of Discrete Outputs:Six (6) Relay; Three (3) Fast DC; Three (3) Normal DC
FeatureBuilt-in RTC
CommunicationEthernet/IP
Operating Frequency:47-63 Hz
UPC10612598518118
Power Consumption:50W; 7.5W (with no 1762 expansion I/O)
Power supply inrush current24V DC: 15 A for 20 ms
Communication port:1 RS232 / RS485; 1 Ethernet; 1 RS232
Supported Protocols:Serial: DF1, ASCII, MODBUS RTU, DNP3, DH485 Ethernet: Ethernet I/P, DNP3, MODBUS TCP/IP
Programming Software:RSLogix 500; RSLogix 500 Micro
Shipping weight:2 lbs
Dimensions:90 x 180 x 87 mm (3.5 x 7.087 x 3.43 in)
Mounting:Panel Mounting / DIN Rail
s

About 1766-L32BXB

The Allen-Bradley 1766-L32BXB is a part of the MicroLogix 1400 Programmable Logic Controller series. It features EtherNet/IP, online editing capabilities, and a built-in LCD. The LCD features a backlight for setting network configuration and viewing the controller and I/O status. The 1766-L32BXB controller requires 24 Volts DC input power and has battery-backed RAM. It supports 32 digital I/O points which are Twelve (12) digital fast 24 Volts DC inputs, Eight (8) digital 24 Volts DC inputs, Six (6) relay outputs, Three (3) fast 24 Volts DC outputs, and Three (3) normal 24 Volts DC outputs. It has a dimension of 3.5 x 7.08 x 3.43 inches and a weight of 2 pounds.

For communication, it has an isolated RS-232/485 port, an Ethernet port, and a non-isolated RS-232 port. It also has an embedded real-time clock to provide a reference for applications that need time-based control. The 1766-L32BXB uses RSLogix 500/Micro programming software (Version 8.1 and above) for programming. For installation, it has Panel or DIN-Rail mounting options and an open enclosure. It is suitable for use in clean, dry, industrial environments with circuits that do not exceed Over Voltage Category II. The 1766-L32BXB controller has various enhanced features like an Ethernet port with DNP3 protocol support and email capabilities. It also has 2 Serial ports with DH485/DF1/Modbus RTU/DNP3/ASCII protocol support, up to 6 embedded 100 kHz high-speed counters (on DC controllers), and a 20 KB memory for user data.

The 1766-L32BXB is MicroLogix 1400 controller features a comprehensive Discrete Input and Output channels such as Twelve (12) Fast 24VDC, Eight (8) Normal 24VDC, Six (6) Relay, Three (3) Fast DC and Three (3) Normal DC outputs. This Discrete I/O variety enables the 1766-L32BXB to be used in application with mixed input voltage and mixed electrical loads. It also allows this controller to be used in applications with counting, totalizing and simple motion controls. Additionally, this controller may also provide the high-speed signals through the embedded high-speed output channels.

The 1766-L32BXB is also provided with a 10KB user program memory and another 10KB for user data. It supports recipe and log data. It is also embedded with a real-time clock for use in applications that require time-based or calendar-based actuations such as control of equipment sets and automatic mode change. Typical processes that use this type of logic are Heating Ventilation and Air Conditioning (HVAC) applications, Building Management Systems (BMS), Facilities Management Systems (FMS) and Water and Waster Treatment Processes.

This controller also has an internal battery back-up for memory retention of the Random Access Memory (RAM) and a back-up memory module for a non-volatile memory area. The high-speed input channels support up to Six (6) channels with100 kHz frequency. This controller also supports Pulse Train Output (PTO) with frequency of 100 kHz and Pulse Width Modulation (PWM) with frequency of 40 kHz. Up to Three (3) PTO and PWM channels may be configured, using RSlogix 500 and RSLogix 500 Micro Programming software.

FAQ for 1766-L32BXB

Does the 1766-L32BXB have built in I/O?


Yes, it has it comes integrated with Twelve (12) Fast 24Vdc Input, Eight (8) Normal 24Vdc Inputs,Six (6) Relay Outputs, Three (3) Fast DC Outputs and Three (3) Normal DC Outputs.

How many I/O modules can you attach to the 1766-L32BXB?


You can add up to 7 1762 I/O Modules.

What are this module’s communication options?


The 1766-L32BXB uses Ethernet/IP communication.

What kind of memory is the 1766-L32BXB equipped with?


The 1766-L32BXB comes with a 20 KB memory.

What frequency does the High Speed Counters support?


Built-in high speed counter inputs support frequency of 0 - 100 kHz.

Can this module be purchased with a warranty?


Yes, the 1766-L32BXB comes with a free one-year warranty from DO Supply, Inc.

Where can I send the 1766-L32BXB to be repaired?


DO Supply, Inc. offers a variety of repair services for the 1766-L32BXB.

Technical Description of 1766-L32BXB

This Allen-Bradley MicroLogix 1400 Module has (12) Digital Fast 24V DC, (8) Digital Normal 24V DC, (2) Analog Inputs, (6) Relay, (3) Fast 24V DC, and (3) Normal 24V DC Outputs.

Repair Services for 1766-L32BXB

Type Lead Time Price Action
Repair Service 2-4 weeks $427.34cartAdd to Cart

Our highly skilled technicians can repair your 1766-L32BXB. Please contact us for additional details about our repair process.

Revisions for 1766-L32BXB

Please refer to the manual for more information about the 1766-L32BXB such as the wiring diagrams, data sheets, firmware information and migration or obsolescence details.

Revision Part # Also Known as Availability
1766-L32BXB Ser A
1766-L32BXB/A, Series A, Rev A Request Quote
1766-L32BXB Ser B
1766-L32BXB/B, Series B, Rev B Request Quote
1766-L32BXB Ser C
1766-L32BXB/C, Series C, Rev C Request Quote
Common misspellings:
  • l766-L32BXB
  • 1766-132BXB
  • 1766-L328XB
  • 1766-L32BX8
  • 1766L32BXB

Reviews for 1766-L32BXB

Product Review

"The 1761-L32BXB is a MicroLogix 1400 controller that features a variety of Discrete input and output signals. This controller is capable of counting, totalizing, accurate date and time-based applications, Pulse Width Modulation and Pulse Train Outputs. Compared to 1766-L32AWA which has general purpose I/O, the 1766-L32BXB presents compatibility with a wider variety of applications. " -DO Supply Tech
