2711C-T6C

Description: The Allen-Bradley 2711C-T6C is a PanelView C300 Component Terminal. This operator terminal features a Color transmissive CSTN passive matrix LCD screen, with diagonal size of 5.7 inches, Display area of 115 x 86 mm (4.53 x 3.39 in.) and resolution of 320 x 240 pixels. It is operated via the touchscreen interface and comes with built-in RS-232 (DH-485), RS-232 (DF1), RS-485, and Ethernet communication interfaces.
Available Now
Request a quote for 2711C-T6C

Description: The Allen-Bradley 2711C-T6C is a PanelView C300 Component Terminal. This operator terminal features a Color transmissive CSTN passive matrix LCD screen, with diagonal size of 5.7 inches, Display area of 115 x 86 mm (4.53 x 3.39 in.) and resolution of 320 x 240 pixels. It is operated via the touchscreen interface and comes with built-in RS-232 (DH-485), RS-232 (DF1), RS-485, and Ethernet communication interfaces.

DO Supply is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with DO Supply's 1-year warranty

Rockwell Disclaimer: The product is used surplus. DO Supply is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because DO Supply is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. DO Supply also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. DO Supply also makes no representations as to your right to install any such firmware on the product. DO Supply will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

disclaimer
credit cards
better business bureau

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via UPS, DHL, and TNT
Repairs: We offer repair service for the 2711C-T6C.
Exchange: Exchange credit for your defective unit available.
Conditions: We sell preowned surplus and refurbished parts.

To speak to a sales representative for pricing & lead time:


Rated 5 with 12 reviews

    Technical Specifications for 2711C-T6C

Compatible Web Browsers:Internet Explorer 7 and 8, Firefox 3.0
Resolution320 x 240
Input Voltage Range18…30V DC (24V DC nom)
Display TypeColor transmissive CSTN passive matrix LCD
BrandAllen-Bradley
Input TypeTouch
Product Family:PanelView Component
Manufacturer:Rockwell Automation
Product Type:PanelView 600 Component
Display Area:115 x 86 mm (4.53 x 3.39 in.)
Backlight:50,000 hours life, min; not replaceable
ListingThis specification list was created by dosupply.com.
Touchscreen:Analog touch Actuation rating: 1 million presses
Communication ports:RS-232 (DH-485), RS-232 (DF1), RS-485 Multi-vendor communication available for Modbus and Siemens MPI devices; USB Port
Product LineComponent Terminal
SeriesC600
Part Number/Catalog No.2711C-T6C
Display Size6 inches
Display ColorColor
Power24 Volts DC
Weight1.5 pounds (approximately)
Heat Dissipation 32 BTU per Hour
Product Lifecycle Status*Discontinued/Obsolete

*The Allen Bradley 2711C-T6C has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 2711C-T6C units instead of migration.

Compatible Web Browsers:Internet Explorer 7 and 8, Firefox 3.0
Resolution320 x 240
Input Voltage Range18…30V DC (24V DC nom)
Display TypeColor transmissive CSTN passive matrix LCD
BrandAllen-Bradley
Input TypeTouch
Product Family:PanelView Component
Manufacturer:Rockwell Automation
Product Type:PanelView 600 Component
Display Area:115 x 86 mm (4.53 x 3.39 in.)
Backlight:50,000 hours life, min; not replaceable
Touchscreen:Analog touch Actuation rating: 1 million presses
Communication ports:RS-232 (DH-485), RS-232 (DF1), RS-485 Multi-vendor communication available for Modbus and Siemens MPI devices; USB Port
Product LineComponent Terminal
SeriesC600
Part Number/Catalog No.2711C-T6C
Display Size6 inches
Display ColorColor
Power24 Volts DC
Weight1.5 pounds (approximately)
Heat Dissipation 32 BTU per Hour
Product Lifecycle Status*Discontinued/Obsolete

*The Allen Bradley 2711C-T6C has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 2711C-T6C units instead of migration.

s

About 2711C-T6C

The 2711C-T6C is an Allen-Bradley PanelView Component C600 Terminal. The Allen-Bradley 2711C-T6C PanelView Component C400 Terminal is one of the most popular terminals that is used for high-end applications with Ethernet or other serial communications. This device uses a color transmissive CSTN passive matrix LCD interface with a variety of controllers and programming ports. Maintaining and installing the drive is easy with the integrated mounting clamps. The built-in navigation tabs guide the users through the development of the application. The 2711C-T6C operator interface comes with 5.7-inch touchscreen display interface.

The 2711C-T6C has a heat dissipation of 32BTU/hour and operating temperature ranging from32 to 122 degrees Fahrenheit. It can be mounted vertically or tilted backwards or forwards at an angle of up to 45 degrees. This operator terminal is c-ULus Listed, CE marked, C-Tick certified.

The 2711C-T6C terminal requires a nominal input voltage of 24 Volts DC nominal and it has an average power consumption of 10 Watts maximum. Disconnect all electrical power from the panel before making the panel cutout. This terminal supports Internet Explorer 7/8 and Firefox 3.0 for easy operation with a PC/remote device. It also has an option to alert the operators about problems by using alarm notifications with various variables. The users can change the language of the terminal for diagnostic messages and configuration. It weighs less than 1.48 pounds and it has a display size of 115 x 86 millimeters (4.53 x 3.39 inches) with a screen resolution of 320 x 240. The built-in dashboard provides a single point of entry for accessing all of the terminal and design operations. Other key features include Unicode language switching, alarm messages, secured programming access, and a history log of the saved tasks in the terminal itself. The 2711C-T6C PanelView Component C600 Terminal is an operator interface device that is designed for monitoring and controlling devices. The 2711C-T6C can only monitor and control devices that are connected to a controller. The 2711C-T6C PanelView Component C600 terminal has an analog touchscreen operator input. The 2711C-T6C terminal is programmable via the USB device port (programming port).

The 2711C-T6C features a 5.7 inches graphic display with a resolution of 320 x 240 pixels and display area of 115 x 86 mm (4.53 x 3.39 in.). This screen size is ideal for medium applications that require display of higher degree of information and larger quantity of graphic objects.

The 2711C-T6C comes with a non-replaceable backlight however, this backlight is designed to operate up to 40,000 Hrs. It also comes with a real-time clock that is battery backed, with battery life expectancy of 5 years, minimum at operating temperature of 25 °C (77 °F).

This PanelView C600 Component also features a touchscreen operator interface, with actuation rating of up to 1 million presses. With the touchscreen operation, faster operator interaction with runtime objects and development of environment is enabled as the interface allows direct interaction.

The 2711C-T6C’s designated programming port is the USB device or the embedded Ethernet port. Communication with preferred controllers such as MicroLogix, SLC, and Micro800 controllers can be established through any of the embedded communication ports, specifically Two (2) RS232 ports which supports DH485 and DF1 communication protocols, RS485 port and Ethernet I/P port.

FAQ for 2711C-T6C

What is the maximum power consumption for the 2711C-T6C?


The maximum power consumption for the 2711C-T6C PanelView Component C600 terminal is 10 Watts operating at 24 volts DC.

What is the enclosure type rating for the 2711C-T6C terminal?


The 2711C-T6C has the following enclosure ratings: NEMA/UL Type 4X, 12, 13 and IEC IP54 and IP65. Please note, NEMA/UL 4X is for indoor use only.

Does the 2711C-T6C PanelView Component C600 Terminal support memory cards?


Yes, the 2711C-T6C has a USB port and SD card slot for memory cards.

What is the price of a 2711C-T6C PanelView Component C600 Terminal?


Submit a quote request, send us an email, or call 800-730-0292 for our best price.

Does DO Supply offer repair services for the 2711C-T6C PanelView Component C600 Terminal?


DO Supply offers repair services for a variety of Allen-Bradley products, such as the 2711C-T6C PanelView Component C600 Terminal. For more information or to submit a repair quote request, please click here.

What is the difference between 2711C-T6C and 2711C-T6M?


The main difference between these operator terminals are the display screen. The 2711C-T6c has a colored screen while the 2711C-T6M has a monochrome screen.

What is the appropriate catalog number of the replacement backlight for the 2711C-T6C?


There is no replacement backlight as the pre-installed one is non-replaceable.

What is the required cutout dimension when flush mounting this unit to an enclosure?


Panel cutout is 136 x 190 mm or 5.35 x 7.48 in.

Technical Description of 2711C-T6C

Allen Bradley PANELVIEW COMP C600 GRAPHIC TERMINAL Touchscreen Model Color Display Operator Inteface HMI

Repair Services for 2711C-T6C

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your 2711C-T6C. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions for 2711C-T6C

Please refer to the manual for more information about the 2711C-T6C such as the wiring diagrams, data sheets and migration or obsolescence details.

Revision Part # Also Known as Availability
2711C-T6C/A, Series A, Rev A Request Quote
2711C-T6C/B, Series B, Rev B Request Quote
2711C-T6C/C, Series C, Rev C Request Quote
2711C-T6CX
2711C-T6C/X, Series X, Rev X Request Quote
Common misspellings:
  • 27l1C-T6C
  • 271lC-T6C
  • 2711CT6C

Reviews for 2711C-T6C

Product Review

"The 2711C-T6C is a PanelView C600 component that boasts of a colored display screen. Compared to the 2711C-T6M which is a monochrome operator terminal, the 2711C-T6C offers a distinct advantage with the capability of displaying process mimic in colored design. Color coded animations as well as plant specific color nomenclature may be implemented in this version of PanelView C600. " -DO Supply Tech

Dimensions For 2711C-T6C

Size
Input Type
Panel Cutout Height in mm
Panel Cutout Width in mm
Terminal Height in mm
Terminal Width in mm
Terminal Overall Depth in mm
Terminal Mounted Depth in mm

Dimensions For 2711C-T6C

Resolutions For 2711C-T6C
