2711P-B4C5D8X

The 2711P-B4C5D8X from Allen Bradley is categorized under the PanelView Plus 6 series, serving as an operator terminal designed for a variety of applications. The device features a 5.5-inch display that is color-capable, presenting information in a clear, vivid format. Its active matrix TFT LCD technology ensures excellent visibility and responsiveness in diverse operational circumstances. The resolution is set at 320 x 240 pixels, providing sufficient clarity for monitoring processes effectively.

This terminal offers both keypad and touchscreen functionality, allowing operators to navigate seamlessly through its interface. It has ten function keys labeled F1 through F10, which facilitate quick access to essential commands. The terminal is powered by an 18-30 VDC input, ensuring the adaptability needed for different systems. Furthermore, a battery-backed real-time clock (RTC) is included to maintain accurate time settings even during power interruptions.

Memory allocation consists of 256 MB of RAM, paired with 512 MB of non-volatile memory, allowing for the storage of critical data and applications. The backlight of the display is non-replaceable, maintaining reliability throughout the product's lifespan. Communication capabilities are reinforced through the inclusion of standard ports such as DF1 and DH-485, ensuring compatibility and ease of integration. The specific communication cable for this module is referenced as 2711-NC14, facilitating proper connectivity. This operator terminal is suited for Series A and Series B applications, making it versatile for various industrial scenarios.
