Product image is representative; revision or series may vary. Contact us to request a specific version.
SP2404
The Control Techniques SP2404 is an AC drive designed for various control applications. It offers a rated active power of 15 kilowatts and can handle a capacity of 10 horsepower. This drive operates within a 380 to 480-volt AC voltage range, with a current rating of 29 amperes.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for SP2404
| Manufacturer | Control Techniques |
|---|---|
| Product Type | AC Drive |
| Product Line | Unidrive SP |
| Part Number | SP2404 |
| Weight | 16.00 lbs (7.26 kg) |
| Protection Class | IP20 |
| Rated Active Power | 15 kilowatts |
| Horsepower Capacity | 10 horsepower |
| Ambient Operating Temperature | 0 to 40°C (in a non-condensing environment) |
| Power Supply Voltage | 380 to 480 Volts AC |
| Input Phase Type | 3-phase input |
| Current Rating | 29 Amperes |
| Input Frequency Range | 48 to 65 Hertz |
| Storage Temperature | -40 to 70°C (in a non-condensing environment) |
| Output Frequency Range | 0 to 550 Hertz |
| Communication Protocol | RS-485 and Modbus RTU (Remote Terminal Unit) |
| Mounting Method | Panel mount |
| Braking Unit | DC injection and dynamic braking transistor |
| Control Method | Vector frequency control, closed-loop induction motor control, open-loop vector control, servo control, regenerative control, and rotor flux control |
The SP2404 from Control Techniques is an AC drive for versatile applications requiring precise control. This drive supports power supply voltages between 380 and 480 Volts AC. With a rated active power of 15 kW, it can deliver up to 10 horsepower to connected systems. The drive demands a 3-phase input with a maximum current rating of 29 Amperes, ensuring ample power for various industrial tasks.
A notable feature of this model is its ability to process input frequencies ranging from 48 to 65 Hertz, providing flexibility in adapting to different inputs. The output frequency can be adjusted from 0 to 550 Hertz, facilitating diverse operational requirements. Regarding temperature management, the SP2404 operates effectively in environments ranging from 0 to 40°C, and it can be stored in temperatures between -40 and 70°C, ensuring consistent performance across varying conditions, provided they are non-condensing.
Communications are streamlined using RS-485 and Modbus RTU (Remote Terminal Unit) protocols, allowing for effective integration into control systems. The drive employs a straightforward panel mount method for mounting, making installation efficient and uncomplicated. The braking system includes both DC injection and dynamic braking transistor functionalities, enhancing overall precision and safety during operation.
This AC drive utilizes various control methods, such as vector frequency control, closed-loop induction motor control, open-loop vector control, servo control, regenerative control, and rotor flux control. These features position the SP2404 as a flexible solution designed to meet the complexities of modern control applications.
