FANUC A03B A03B-0807-C153

Product image is representative; revision or series may vary. Contact us to request a specific version.

A03B-0807-C153

|
Need a Specific Revision?

The FANUC A03B-0807-C153 output module is designed to manage 16 output points effectively. This module operates with a direct current (DC) voltage output, ranging from 12 V to 24 V.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for A03B-0807-C153

ManufacturerFANUC
Product LineA03B
Part NumberA03B-0807-C153
Weight0.94 lbs (0.43 kg)
ProductOutput Module
Number of Points16
Voltage Output TypeDC
Minimum Voltage12 V
Maximum Voltage24 V
Maximum Ambient Temperature60 degrees Celsius
Minimum Ambient Temperature0 degrees Celsius
Operating Humidity Limit80% (non-condensing)
Storage Humidity Limit80% (non-condensing)
Operating Altitude1000 meters above sea level
Protection ClassIP20
Request a Repair

The part A03B-0807-C153 manufactured by FANUC is an output module featuring 16 discrete output points. This module is capable of delivering direct current (DC) voltage outputs, adjustable from a minimum of 12 V to a maximum of 24 V. The physical weight of the module is approximately 0.93 lbs, making it manageable for integration into various systems.

Designed for reliable operation, the A03B-0807-C153 can function within temperatures ranging from 0 to 60 degrees Celsius, ensuring efficient performance in standard conditions. It is also suitable for use in environments up to 1000 meters above sea level.

When it comes to humidity, the module operates effectively in conditions of up to 80% relative humidity without condensation, both during operation and while in storage. The IP20 protection rating provides basic safeguards against solid particles, making it suitable for use in controlled environments where exposure to dust and moisture is limited.
