FANUC A06B A06B-6117-H302

Product image is representative; revision or series may vary. Contact us to request a specific version.

A06B-6117-H302

|
Need a Specific Revision?

The A06B-6117-H302 from FANUC is a servo amplifier module designed for high-performance motion control applications. With a rated output power of 11 kW, it operates efficiently across various conditions.

Out of stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for A06B-6117-H302

ManufacturerFANUC
Product LineA06B
Part NumberA06B-6117-H302
Weight15.00 lbs (6.80 kg)
Product DescriptionServo Amplifier Module
Ambient Humidity90% RH or less (No condensation)
Maximum Ambient Operating Temperature55°C
Output Voltage200-240 VAC
Minimum Ambient Operating Temperature0°C
Rated Output Current19A (L-axis), 19A (M-axis)
Output Frequency Range0.1 - 800 Hz
Input Voltage283-339 VDC
Rated Input Power11 kW
Input Frequency50/60 Hz
Request a Repair

FANUC's A06B-6117-H302 is an advanced servo amplifier module designed to optimize control in various industrial applications. This module is engineered with an input voltage range of 283 to 339 VDC, allowing it to support demanding performance requirements. An output voltage range from 200 to 240 VAC allows for flexible integration in existing systems.

Operating temperatures can vary significantly, with the module functioning effectively between a minimum of 0°C and a maximum of 55°C. Additionally, it can endure ambient humidity levels of up to 90% relative humidity, provided that condensation is not present. This capability makes it suitable for a range of environments.

Regarding output, the A06B-6117-H302 provides a rated output current of 19A on both the L-axis and M-axis, ensuring robust performance in multi-axis systems. The output frequency range is quite broad, extending from 0.1 Hz to 800 Hz, facilitating precise control over motor speed and torque. Designed for operational efficiency, the amplifier has a rated input power of 11 kW and accommodates input frequencies of 50 or 60 Hz, which covers typical industrial standards.
