IC200NAL211

The GE Fanuc Emerson IC200NAL211 serves as a compact and robust programmable logic controller within the Versamax range. Designed to operate at 24 Volts DC, this PLC is equipped with a total of six discrete inputs and four discrete outputs, allowing for effective control over connected devices. It comprises a single analog input as well, which is essential for reading voltage signals.

The control system utilizes a Single Pole Single Throw (SPST) output type, providing reliability in various switching applications. With a significant user program logic memory capacity of 2,000 words and registration capability of 256 words, this unit is highly functional for programming complex operational logic. Although the unit supports up to 10 inputs and outputs, those are non-expandable, allowing for direct applications without the need for expansion modules.

Two analog pots are incorporated into the system for data adjustments, facilitating precision tuning as required for specific applications. The analog input range of 0 to 10 Volts DC permits versatility in its operation within different environments.

Communication is streamlined through RJ-45 and RS-232 connectors, ensuring integration with existing setups without difficulty. The maximum resistive load capacity for the relay mounted within the PLC is rated at 2 Amperes, whether operating at 5 Volts DC or 240 Volts AC.

For operational feedback, the controller incorporates three status LED indicators and individual indicators for each input and output point, aiding in real-time monitoring. With a quick scan rate of 1 millisecond per 10 instructions, the IC200NAL211 is engineered to provide responsive control solutions for varying automation needs.
