IC200PWR201

Rated 4.5 with 8 reviews
top legal disclaimer
top legal disclaimer

credit cards accepted
better business bureau

IC200PWR201

Revisions: B E
Description: The GE Fanuc IC200PWR201 module is a power supply module from the Versamax family. It has an input voltage range between 9.5 and 15 Volts DC,12 Volts DC nominal voltage, and an output voltage of 5 Volts DC and 3.3 Volts DC.
In Stock Ships Today
Request a quote for IC200PWR201

Description:

The GE Fanuc IC200PWR201 module is a power supply module from the Versamax family. It has an input voltage range between 9.5 and 15 Volts DC,12 Volts DC nominal voltage, and an output voltage of 5 Volts DC and 3.3 Volts DC.



top legal disclaimer
disclaimer
credit cards
better business bureau
Revisions: B E

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via DHL, UPS, Fedex, and TNT
Repairs: We offer repair service for the IC200PWR201.
Exchange: Exchange credit for your defective unit available.

To Speak to a sales representative for pricing & lead time:

phone

International
919-205-4392

Rated 4.5 with 8 reviews

    Technical Specifications for IC200PWR201

BrandGE Fanuc
SeriesVersamax
Part NumberIC200PWR201
Input Voltage9.6-15 Volts DC, and 12 Volts DC nominal
Output Voltage5 Volts DC and 3.3 Volts DC
Extended Power No
Isolated PowerNo
Input Power11 Watts
Holdup Time 10 Milliseconds
Inrush Current 25 Amperes at 12 Volts DC and 30 Amperes at 15 Volts DC
Protection Short circuit, overload, reverse polarity
Total Output Current 1.5 A maximum
3.3V Output Current 0.25 A maximum
Output Current 1.5 A minus the 3.3 V current used, maximum
Dimensions49 mm (1.93 in) x 133.4 mm (5.25 in) x 39 mm (1.54 in),
BrandGE Fanuc
SeriesVersamax
Part NumberIC200PWR201
Input Voltage9.6-15 Volts DC, and 12 Volts DC nominal
Output Voltage5 Volts DC and 3.3 Volts DC
Extended Power No
Isolated PowerNo
Input Power11 Watts
Holdup Time 10 Milliseconds
Inrush Current 25 Amperes at 12 Volts DC and 30 Amperes at 15 Volts DC
Protection Short circuit, overload, reverse polarity
Total Output Current 1.5 A maximum
3.3V Output Current 0.25 A maximum
Output Current 1.5 A minus the 3.3 V current used, maximum
Dimensions49 mm (1.93 in) x 133.4 mm (5.25 in) x 39 mm (1.54 in),
s

About IC200PWR201

The GE Fanuc IC200PWR201 power supply module supplies electrical power to backplane devices, input and output (I/O) modules, network interface units (NIUs), and central processing units (CPUs). The module has neither isolated power nor extended power, unlike other Versamax power supply modules. It serves as the main power source for backplane devices in the I/O station, or it can also be used as a supplementary power supply in larger input and output applications. The IC200PWR201 power supply module has an input voltage range between 9.5 and 15 Volts DC as well as 12 Volts DC nominal voltage, and it has an output voltage of 5 Volts or 3.3 Volts DC. It has an input power rating of 11 Watts and a holdup time of up to 10 milliseconds.



The GE Fanuc Versamax IC200PWR201 power supply module has an inrush current rating of 25 Amps at 12 Volts DC voltage and 30 Amps at 15 Volts DC voltage. The unit plays a major role in protecting the systems against overloading, short circuits, and reverse polarity. It has a total output current not exceeding 15 Amps. With an output voltage of 3.3 Volts DC, the module can yield an output current up to 0.25 Amps while an output voltage of 5 Volts DC will yield 1.2 Amps of current minus the 3.3 Volts of used voltage. The IC200PWR201 module has dimensions of 49 millimeters (1.93 inches) x 133.4 millimeters (5.25 inches) x 39 millimeters (1.54 inches) not including the height of the DIN rail it is mounted on and the carrier.

Repair Services for IC200PWR201

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your IC200PWR201. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions for IC200PWR201

Please refer to the manual for more information about the IC200PWR201 such as the wiring diagrams, data sheets, firmware information and migration or obsolescence details.

Revision Part # Also Known as Availability
IC200PWR201B
IC200PWR201-B, Series B, Rev B Request Quote
IC200PWR201E
IC200PWR201-E, Series E, Rev E Request Quote
Common misspellings:
  • 1C200PWR201
  • IC2o0PWR201
  • IC20oPWR201
  • IC200PWR2o1
  • IC200PWR20l
  • IC200PWR201

Dimensions For IC200PWR201

Size
Input Type
Panel Cutout Height in mm
Panel Cutout Width in mm
Terminal Height in mm
Terminal Width in mm
Terminal Overall Depth in mm
Terminal Mounted Depth in mm

Dimensions For IC200PWR201

Resolutions For IC200PWR201

Technical Specifications
BrandGE Fanuc
SeriesVersamax
Part NumberIC200PWR201
Input Voltage9.6-15 Volts DC, and 12 Volts DC nominal
Output Voltage5 Volts DC and 3.3 Volts DC
Extended Power No
Isolated PowerNo
Input Power11 Watts
Holdup Time 10 Milliseconds
Inrush Current 25 Amperes at 12 Volts DC and 30 Amperes at 15 Volts DC
Protection Short circuit, overload, reverse polarity
Total Output Current 1.5 A maximum
3.3V Output Current 0.25 A maximum
Output Current 1.5 A minus the 3.3 V current used, maximum
Dimensions49 mm (1.93 in) x 133.4 mm (5.25 in) x 39 mm (1.54 in),
BrandGE Fanuc
SeriesVersamax
Part NumberIC200PWR201
Input Voltage9.6-15 Volts DC, and 12 Volts DC nominal
Output Voltage5 Volts DC and 3.3 Volts DC
Extended Power No
Isolated PowerNo
Input Power11 Watts
Holdup Time 10 Milliseconds
Inrush Current 25 Amperes at 12 Volts DC and 30 Amperes at 15 Volts DC
Protection Short circuit, overload, reverse polarity
Total Output Current 1.5 A maximum
3.3V Output Current 0.25 A maximum
Output Current 1.5 A minus the 3.3 V current used, maximum
Dimensions49 mm (1.93 in) x 133.4 mm (5.25 in) x 39 mm (1.54 in),
About

The GE Fanuc IC200PWR201 power supply module supplies electrical power to backplane devices, input and output (I/O) modules, network interface units (NIUs), and central processing units (CPUs). The module has neither isolated power nor extended power, unlike other Versamax power supply modules. It serves as the main power source for backplane devices in the I/O station, or it can also be used as a supplementary power supply in larger input and output applications. The IC200PWR201 power supply module has an input voltage range between 9.5 and 15 Volts DC as well as 12 Volts DC nominal voltage, and it has an output voltage of 5 Volts or 3.3 Volts DC. It has an input power rating of 11 Watts and a holdup time of up to 10 milliseconds.



The GE Fanuc Versamax IC200PWR201 power supply module has an inrush current rating of 25 Amps at 12 Volts DC voltage and 30 Amps at 15 Volts DC voltage. The unit plays a major role in protecting the systems against overloading, short circuits, and reverse polarity. It has a total output current not exceeding 15 Amps. With an output voltage of 3.3 Volts DC, the module can yield an output current up to 0.25 Amps while an output voltage of 5 Volts DC will yield 1.2 Amps of current minus the 3.3 Volts of used voltage. The IC200PWR201 module has dimensions of 49 millimeters (1.93 inches) x 133.4 millimeters (5.25 inches) x 39 millimeters (1.54 inches) not including the height of the DIN rail it is mounted on and the carrier.
