Product image is representative; revision or series may vary. Contact us to request a specific version.
AD75M1
The AD75M1 from Mitsubishi is a dedicated positioning module tailored for precise control of a single axis. It employs a point-to-point control method and supports a robust SSCNET interface.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for AD75M1
| Manufacturer | Mitsubishi |
|---|---|
| Product Type | Positioning Module |
| Product Line | A Series |
| Part Number | AD75M1 |
| Weight | 0.25 lbs (0.11 kg) |
| Number of Control Axes | 1 Axis |
| Interpolation Function | None |
| Control Method | PTP (Point To Point) control |
| Number of Occupied Input Points | 32 points |
| Number of Occupied Output Points | 32 points |
| Max. Connection Distance | 30 m |
| Control Interface | SSCNET |
| Housing Material | Resin Case |
| Max. Pulse Speed | 200,000 pulses per second |
| Min. Operating Temperature | -10°C |
| Max. Operating Temperature | 55°C |
The AD75M1 positioning module by Mitsubishi belongs to the A Series and is engineered for optimal control over a single axis. This module operates using point-to-point (PTP) control without interpolation functions, providing straightforward and precise motion management. It is equipped with 32 input and 32 output points, facilitating versatile configurations in control applications.
Supporting a maximum connection distance of 30 meters, the AD75M1 ensures flexibility in installation. The module's control interface is based on SSCNET, delivering fast and reliable communication. The unit offers an impressive maximum pulse speed capability of 200,000 pulses per second, allowing it to handle rapid movements efficiently.
Constructed with a resin case, the AD75M1 provides adequate protection in various environments. Its operational temperature range extends from -10°C to 55°C, making it resilient against environmental fluctuations. Overall, the AD75M1 is a reliable choice for users seeking a specialized module for single-axis positioning requirements.
- AD75MI
