Product image is representative; revision or series may vary. Contact us to request a specific version.
AY51
The Mitsubishi AY51 serves as a sink loading output module with capabilities for transistor output. With 32 points available and a rated load voltage of 12/24 VDC, this module supports diverse applications.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for AY51
| Manufacturer | Mitsubishi |
|---|---|
| Product Type | Sink Loading Output Module |
| Product Line | A Series |
| Part Number | AY51 |
| Weight | 1.13 lbs (0.51 kg) |
| Output Type | Transistor Output |
| Number of Points | 32 Points |
| Rated Load Voltage | 12/24 VDC |
| Max. Load Current Per Point | 0.5 A |
| Max. Load Current Per Common | 3.3 A |
| Output Response Time (OFF to ON) | 2 ms or less |
| Output Response Time (ON to OFF) | 2 ms or less (resistive load) |
| Operating Temperature Range | 0 to 55°C |
| Storage Temperature Range | -20 to 75°C |
| Relative Humidity | 10 to 90% (non-condensing) |
| Installation Altitude | 2000 m |
| Pollution Degree | Degree 2 |
The AY51 output module from Mitsubishi's A Series is designed for applications that require sink loading capabilities. This module operates with transistor outputs and includes a total of 32 output points. It is rated for load voltages of 12 VDC or 24 VDC. Each output point can manage a maximum load current of 0.5 A, while the common connection can handle up to 3.3 A.
In terms of speed, the module achieves output response times of 2 milliseconds or less when switching from OFF to ON states, and likewise for transitions from ON to OFF under resistive load conditions. This prompt response contributes to its effectiveness in dynamic applications.
The AY51 functions reliably across a specified operating temperature range of 0 to 55 degrees Celsius, while its storage capabilities allow it to endure temperatures spanning from -20 to 75 degrees Celsius. Additionally, it can perform in environments with relative humidity measures from 10% to 90%, provided that conditions are non-condensing. At a maximum installation altitude of 2000 meters, the module is suitable for a variety of setups. Notably, it is rated for pollution degree 2, making it resilient against common environmental contaminants. Overall, the AY51 module is a flexible output solution for various automation applications.
